About this product
- Materials: Steel
- Size: 2730*1225*2115mm
- Color: Yellow
- Tire certification: Other
- Load capacity: Other
- Horsepower: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
About this product
- Materials: Steel
- Size: 2730*1225*2115mm
- Color: Yellow
- Tire certification: Other
- Load capacity: Other
- Horsepower: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
Product details
| Materials | Steel |
|---|---|
| Size | 2730*1225*2115mm |
| Color | Yellow |
| Tire certification | Other |
| Load capacity | Other |
| Horsepower | Other |
| Power source | Other |
| Engine capacity | Other |
| Drive wheel | Other |
From the supplier
1.Power System. GS forklifts are all with reliable power accessories. All accessories are support by domestic and world famous brand, high quality, reliable after-sales. We follow the strict environmental design, all engines match the China Ⅲ or even higher emission standards.
2.Super comfortable. GSEQUIP forklifts are all with comfortable driving space, adjustable steering wheel and seats,super low and non-slip step, suspension steering axle, storing space, and convenient LCD panel.
3.GSEQUIP forklift can equip with different attachments according to your need.
1
Model
FD30
2
Power Type
Diesel
3
Rated Capacity
kg
3000
4
Load Centre
mm
500
Characteristic & Dimension
5
Lift Height
mm
3000
6
Fork Size
L*W*T
mm
1070*125*45
7
Mast Tilt Angle
F/R
Deg
6°/12°
8
Front Overhang(Wheel centre to fork face)
mm
475
9
Overall Dimension
Length to face of fork (without fork)
mm
2730
10
Overall Width
mm
1225
11
Mast Lowered Height
mm
2115
12
Overhead Guard Height
mm
2090
13
Turning Radius (outside)
mm
2440
14
Min.insecting aisle
mm
2490
Performance
15
Speed
Travel (Empty load)
km/h
19
16
Lifting (Full load)
mm/s
550
17
Max.Gradeability
%
20
Chassis
18
Tire
Front
28*9-15-12PR
19
Rear
6.50-10-10PR
20
Wheelbase
mm
1700
21
Service weight
kg
4300
22
Battery
Voltage/Capacity
V/Ah
12/80
23
Engine
Model
S4S
24
Manufacture
MITSUBISHI
25
Rated output/r.p.m.
kw
34.4/2250
26
Rated torque/r.p.m.
N·m
169/1700
27
No.of Cylinder
4
28
Bore*Stroke
mm
94×120
29
Displacement
cc
3331
30
Transmission
Type
Hydraulic
31
Stage (FWD/RVS)
1.1
32
Operating Pressure for Attachment
Mpa
17.5
