The 6-channel 1080P Vehicle 360° Panoramic Imaging System supports input from 6 wide-angle HD cameras and complies with BSIS/MOIS regulations. The system features an upgraded algorithm with integrated pedestrian detection, LDW (Lane Departure Warning), FCW (Forward Collision Warning), BSD (Blind Spot Detection), and DMS (Driver Monitoring System) algorithms, enabling intelligent vehicle monitoring both inside and outside the vehicle. This system is suitable for various long vehicles, including articulated buses, cranes, long trailers, container trucks, and fire trucks.

Features

【Compliant with UN ECE R151+R159, R158 regulations】It meets the requirements of BSIS/MOIS/RVCS regulations, eliminating side,front and rear blindness of large vehicles
【6CH 360° Around View】6CH 360° surround view image system, suitable for all kinds of vehicles
【One-minute Calibration】Automatic calibration can be finished in 1 minute, and it supports automatic plane correction, saving time and effort
【Dual AI Cores】Independent dual AI core processing with 2TOPS computing power delivers a smoother, more precise experience
【LDW+FCW+BSD】Built-in AI algorithm, integrated with LDW+FCW+both sides BSD 360 degree detection, is able to detect lane departure, forward collision and overtaking/merging around the vehicle, and then to give an alarm
【Pedestrian Detection】The control box is equipped with built-in processing capabilities, delivering more precise pedestrian detection. Each camera channel can cover a detection range of over 10 meters, providing comprehensive coverage with no blind spots
【DMS Driver Fatigue Monitoring】Supports DMS algorithm, capable of monitoring driver fatigue
【Remote Vehicle Management】It can be connected to the platform via 4G to achieve remote vehicle management
【Other Functions】Optional capacitive touch screen; trigger wire and GPS access are both supported

360 Degree Surround View Control box: Video input Max.6CH×1080P AHD (25/30)FPS Video output 1-CH 1080P AHD/VGA/CVBS(D1)/RTSP Trigger input 1-CH backward trigger,1-CH let trigger, 1-CH right trigger, trigger 1/2/3 are extended input triggers for user-defined setting TV System: PAL /NTSC Storage Max. 1×512G SD card+1×2T SSD card Waterproof rating IP69K Language English,French,German. Dutch.Chinese Power supply 10-32V Operating current <2A/12V Operating temperature -20℃ ~ 70℃ Storage temperature -40℃ ~ 85℃ Operating humidity 10%-95%

Why do you need 6CH Waterproof 360 surround view system?

How can large vehicles ensure compliance with international and regional safety regulations on the road?
How can long vehicles drivers enhance their awareness in complex road conditions and environments?
How can a single system provide comprehensive warnings during vehicle operation?
How can calibration be completed quickly to save costs?
How can remote vehicle management be achieved to improve management efficiency?

Compliant with UN ECE R151+R159, R158 regulations, eliminate lateral, anterior and rear blindness

6CH 1080P image, 360° seamless splicing

Specially designed for articulated buses, cranes, long trailers, container trucks, fire fighting trucks and other super long vehicles, 6CH ultra-wide angle HD cameras are spliced seamlessly to achieve real 360° panoramic bird view and zero blind spot monitoring, assisting in safe driving. Meanwhile, it also supports 360 surround view with 4 channels and other applications with 2 channels. In addition, expanding more camera inputs is feasible through Network Switch, meeting the monitoring demands of all kinds of vehicles.

One-minute calibration
The 360 system comes with automatic calibration, which can be done in 1 minute through the touch screen or remote control. Only 6 calibration mats are needed, and they can be placed randomly to achieve accurate calibration.
Calibration of 6 channel surround view system

Calibration of 4 channel surround view system

Dual AI Cores for Independent Processing, 2TOPS Computing Power
The control box supports dual AI cores for independent processing, achieving 2TOPS of AI computing power. This enables efficient execution of complex deep learning tasks and real-time image processing. It provides real-time analysis of complex road conditions and intelligent prediction of potential risks, ensuring comprehensive safety.

Built-in AI algorithm, integrating LDW+FCW+BSD full area detection
Built-in AI algorithm, integrated with LDW+FCW+both sides BSD 360 degree detection, is able to detect lane departure, forward collision and overtaking/merging around the vehicle, and then to give an alarm.

AI-based pedestrian detection, all-around vehicle surround monitoring.
The control box is equipped with built-in processing capabilities, delivering more precise pedestrian detection. Each camera channel can cover a detection range of over 10 meters, providing comprehensive coverage with no blind spots.

Supports DMS algorithm, capable of monitoring driver fatigue.
Monitors driver fatigue and issues auditory and visual alarm.

Support radar access, and protect vehicle whole body
Able to work with radar and supporting the overlay of real-time video and audio, it could actively warn the driver to avoid obstacles and other potential hazards.

Multiple viewing models, 3D and 2D switchable
360° panoramic image system, in which user can switch 3D/2D view freely, meets the needs of all kinds of viewing angles

Remote vehicle management
It could be connected to platform to achieve remote vehicle management via 4G network.
