About this product
- Materials: aluminum
- Size: 0.8、1.0、1.2、1.6、2.0、2.4、3.0、3.2、4.0、5.0、6.0(mm)
- Color: silver color
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Hebei, China
About this product
- Materials: aluminum
- Size: 0.8、1.0、1.2、1.6、2.0、2.4、3.0、3.2、4.0、5.0、6.0(mm)
- Color: silver color
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Hebei, China
Product details
| Materials | aluminum |
|---|---|
| Size | 0.8、1.0、1.2、1.6、2.0、2.4、3.0、3.2、4.0、5.0、6.0(mm) |
| Color | silver color |
Product details
| Materials | aluminum |
|---|---|
| Size | 0.8、1.0、1.2、1.6、2.0、2.4、3.0、3.2、4.0、5.0、6.0(mm) |
| Color | silver color |
From the supplier
ER5356 is the aluminum magnesium alloy wire with a small amount of titanium. It has a good corrosion resistance, heat resistance, good crack resistance, high strength, good ductility. Weld anodizing is white, which can provide a good color match. It is a universal type welding widely.
Top Features
1. General purpose filler alloy for 5XXX series alloys
2. Superior Wetting – unparalleled bead profile and appearance which are critical for groove and fillet welds on aluminum trailer beds
3. Enhanced Puddle Clarity and Control – Chuanwang 5356 has an engineered chemical composition developed specifically to outperform standard ER5356 electrodes and gives the operator unprecedented control
4. Maximum Arc Performance and Stability – proprietary manufacturing processes give 5356 the smoothest surface finish in the industry, making it ideal for automatic applications on formed truck panels
Chemical Composition (%)
Elements
Si
Fe
Cu
Mn
Mg
Cr
Zn
Ti
Al
Requirements
0.25
0.4
0.1
0.05-0.2
4.5-5.5
0.05-0.20
0.1
0.06-0.2
Balance
Physical Properties
Test Name
Melt Temperature
Electrical Conductivity
Heat Conductivity
Tensile Strength
Yield Strength
Extensibility
Linear Expansivity
Density
（℃）
%IACS
W/m.k
(MPa)
(MPa)
(%)
10-6/K（20-100℃）
g/cm3
Requirements
574～638
29
110~140
250~300
70~85
15~25
24.1
2.64
Chemical composition standard: GB/T3190-1998
Wire standard: GB10858-2008, ANSI/AWS A5.10-92
Certificate: ISO9001:2008
Packing:
Mig: 7kg/ spool; 9kg/spool; 20kg/coil; 144 spools/ pallet;
Tig-1M(L): 5kg/bag *2bags/ carton; 10kg/bag /carton; 100 cartons/ pallet;
Package with label and material test report.
Typical Applications
Automotive bumpers and supports
Structural frames in the shipbuilding industry
Bicycle frames
High speed groove welds on formed truck panels
Multi-pass fillet and lap welds on 6XXX series base materials
Robotic fillet welds on trailer tanks requiring minimal post-weld clean up
Welding Positions:All
Shielding Gas: 100% Argon Mixed Shielding Gas
