Specifications

Model

BI-3000

BI-1000

BI-800

Canopy Specifications

Mattress (canopy)

450mm

450mm

450mm

Access Port

6 (2 Iris ports)

6 (2 Iris ports)

4 (2 Iris ports)

Self-sealing Tube Ports

4

4

2

Front Access Panel

826x310mm

826x310mm

826x310mm

Mattress Tray Size

630x360mm

630x360mm

630x360mm

Technical Specifications

Temperature Mode (Servo Controlled)

air, infant

air, infant

air

Air Temperature Adjustment Range

20°C~37°C, 37~39°C

20°C~37°C, 37~39°C

20°C~37°C

Infant Temperature Adjustment Range

30°C~37°C, 37~38°C

30°C~37°C, 37~38°C

N/A

Infant Sensor Accuracy

≤0.3°C

≤0.3°C

N/A

Relative Humidity Display Range

5%~99%

N/A

N/A

Temperature Fluctuation

≤0.5°C

≤0.5°C

≤0.5°C

Uniformity of Mattress Temperature

≤0.8°C

≤0.8°C

≤0.8°C

Time to Warm Up

≤30 min

≤30 min

≤30 min

Noise Level within Canopy

≤55dB

≤55dB

≤55dB

Alarms

Power Failure Alarm

Yes

Yes

Yes

Fan Failure Alarm

Yes

Yes

Yes

Sensor Failure Alarm

Yes

Yes

Yes

Air Temperature Deviation Alarm

±3.0°C

±3.0°C

±3.0°C

Infant Temperature Deviation Alarm

±1.0°C

±1.0°C

N/A

Air Temperature Exceeds set Limit Alarm

≤38.0°C; ≤40.0°C

≤38.0°C; 40.0°C

≤38.0°C

Infant Temperature Exceeds set Limit alarm

≤38.0°C; ≤39.0°C

≤38.0°C; 39.0°C

N/A

System Failure Alarm

Yes

Yes

N/A

Mute Alarm Function

Yes

Yes

N/A

Operational Environment

Temperature within Operational Environment

+20°C~+30°C

+20°C~+30°C

+20°C~+30°C

Relative Humidity within Operational Environment

5%~99%

5%~99%

5%~99%

Velocity of Air Flow within Operational Environment

＜0.3m/s

＜0.3m/s

＜0.3m/s

Other Specifications

RS-232 connector

Yes

Yes

N/A

Tilt of Infant Bed (Adjustment Range)

±10° step-less

±10° step-less

N/A

Maximum Load of Mattress Tray

5kg

5kg

5kg

Maximum Load of IV Stand

2kg

2kg

2kg

Maximum Load of Cabinet

6kg

6kg

N/A
