BelFone BF-AP3016 Analog Two-Way Radio
Fujian BelFone Communications Technology Co. Ltd
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
BelFone BF-AP3016 Analog Two-Way Radio
Fujian BelFone Communications Technology Co. LtdThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Size: 54*30*93mm
- Color: Black
- Power source: Battery Powered
- Frequency band: Other
- Brand: Other
- Style: Handheld
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Size: 54*30*93mm
- Color: Black
- Power source: Battery Powered
- Frequency band: Other
- Brand: Other
- Style: Handheld
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Size | 54*30*93mm |
|---|---|
| Color | Black |
| Power source | Battery Powered |
| Frequency band | Other |
| Brand | Other |
| Style | Handheld |
| Use | CivilianRadio |
| Working distance | 1～5m |
| Weight | 159g |
Product details
| Size | 54*30*93mm |
|---|---|
| Color | Black |
| Power source | Battery Powered |
| Frequency band | Other |
| Brand | Other |
| Style | Handheld |
| Use | CivilianRadio |
| Working distance | 1～5m |
| Weight | 159g |
From the supplier
BF-AP3016, the new generation analog two-way radio, can adapt multi-scenes for its many outstanding advantages in many aspects like modern design, strong signal penetration, long battery life, excellent sound quality, drop resistance and compression ability, etc., guaranteeing the continuity and reliability effectively.
VOX
Channel Matching
Squelch Level
Type-C Charging Mode
Busy Channel Locking
CTCSS/CDCSS
Special Signal Mode
Noise Reduction (Optional)
General Frequency Range UHF: 400-480MHz Channel Capacity 16 Channel Spacing 25 KHz /12.5 KHz Frequency Stability ≤±2.5 ppm Antenna Impedance 50Ω Operating Voltage DC3.7V (±20%) Battery Capacity 1800mAh Dimensions (L×W×H) 54*30*93mm Weigh 159g Transmitter RF Output Power ≤3W 4FSK Modulation 11KφF3E/16KφF3E FM Modulation ≤±2.5KHz /±5.0KHz Adjacent Channel Power 60dB Audio Distortion ＜5% Receiver Sensitivity ≤-122dBm(12dB SINAD) Intermodulation ≥60dB(Wide)/ 55dB (Narrow) Adjacent Channel Selectivity ≥60dB(Wide)/ 55dB(Narrow) Spurious Response Rejection ≥60dB(Wide)/ 55dB(Narrow) Rated Audio Output Power 0.5W Audio Distortion ≤5% Environmental Specifications Operating Temperature -20℃～+60℃ Storage Temperature -30℃～+70℃
From the supplier
BF-AP3016, the new generation analog two-way radio, can adapt multi-scenes for its many outstanding advantages in many aspects like modern design, strong signal penetration, long battery life, excellent sound quality, drop resistance and compression ability, etc., guaranteeing the continuity and reliability effectively.
VOX
Channel Matching
Squelch Level
Type-C Charging Mode
Busy Channel Locking
CTCSS/CDCSS
Special Signal Mode
Noise Reduction (Optional)
General Frequency Range UHF: 400-480MHz Channel Capacity 16 Channel Spacing 25 KHz /12.5 KHz Frequency Stability ≤±2.5 ppm Antenna Impedance 50Ω Operating Voltage DC3.7V (±20%) Battery Capacity 1800mAh Dimensions (L×W×H) 54*30*93mm Weigh 159g Transmitter RF Output Power ≤3W 4FSK Modulation 11KφF3E/16KφF3E FM Modulation ≤±2.5KHz /±5.0KHz Adjacent Channel Power 60dB Audio Distortion ＜5% Receiver Sensitivity ≤-122dBm(12dB SINAD) Intermodulation ≥60dB(Wide)/ 55dB (Narrow) Adjacent Channel Selectivity ≥60dB(Wide)/ 55dB(Narrow) Spurious Response Rejection ≥60dB(Wide)/ 55dB(Narrow) Rated Audio Output Power 0.5W Audio Distortion ≤5% Environmental Specifications Operating Temperature -20℃～+60℃ Storage Temperature -30℃～+70℃
