About this product
- Materials: Copper Conductor , PVC insulation , PVC jacket
- Size: 2*1.5+1mm2
- Color: white jacket , grey jacket
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Latin America
- Made in: Henan, China
About this product
- Materials: Copper Conductor , PVC insulation , PVC jacket
- Size: 2*1.5+1mm2
- Color: white jacket , grey jacket
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Latin America
- Made in: Henan, China
Product details
| Materials | Copper Conductor , PVC insulation , PVC jacket |
|---|---|
| Size | 2*1.5+1mm2 |
| Color | white jacket , grey jacket |
From the supplier
Product Description:
BVVB : Copper core PVC insulated and sheathed flat cable
The insulation material and sheath material of BVVB wires are all polyvinyl chloride. According to different performances, the product can be divided into three categories: insulation, flame retardant, and fire resistance. A sheathed cable refers to a single-core or multi-core wire with a sheath: a layer of white polyvinyl chloride sheath with several BV wires inside. This kind of wire is generally a copper core wire. In addition to an insulating layer outside the wire, there is a protective layer outside the wire.
Product Features：
The PVC insulated wire belong to the series of laying wires,which are mainly suitable for laying at the fixed places.They are widesly used as connectors of driving,lighting,electric equipments,instrument and telecommunication equipments with rated voltage to 450/750V. The long-term allowable working temperature of BVVB products should not exceed 70℃, but under the condition that it can prevent the flow of thermoplastic and allow to reduce the insulation resistance, the PVC mixture that can be used continuously at 90℃ will shorten the total working time. The working temperature can be increased to 105°C.The laying temperature of the cable should not be lower than 0℃, the allowable bending radius of cables with an outer diameter (D) of less than 25mm should be no less than 4D, and the allowable bending radius of cables with an outer diameter (D) of 25mm or more should not be less than 6D.
Product parameters：
BVVB, BLVVB 300/500V
Nominal Section
Structure of Cores Core x No./Dia
Max. Outer Dia
(mm2)
Reference Weight(kg/km)
Conductor Resistance at 20oC≤(Ω/km)
(mm2)
(mm)
Aluminum
Copper
Copper
Aluminum
Copper
Aluminum
2x0.75
2x1/0.97
4.6x7.0
43.7
24.5
2x1.0
2x1/1.13
4.8x7.4
51.0
18.1
2x1.5
2x1/1.38
5.4x8.4
65.9
12.1
2x2.5
2x1/1.78
6.2x9.8
6.2x9.8
95.7
64.9
7.41
11.8
2x4
2x7/0.85
6.8x11.0
7.2x11.5
146.0
80.7
4.61
7.39
2x6
2x7/1.04
7.4x12.0
8.0x13.0
200.0
104
3.08
4.91
2x10
2x7/1.35
9.6x16.0
9.6x16.0
323.0
177
1.83
3.08
3x0.75
3x1/0.97
4.6x9.4
62.6
24.5
3x1.0
3x1/1.13
4.8x9.8
74.3
18.10
3x1.5
3x1/1.38
5.4x11.5
95.6
12.10
3x2.5
3x1/1.78
6.2x13.5
6.2x13.5
140
93.9
7.41
11.8
3x4
3x7/0.85
7.0x15.0
7.4x16.5
220
123
7.41
7.39
3x6
3x7/1.04
7.4x17.0
8.0x18.0
295
153
4.61
4.91
3x10
3x7/0.35
9.6x22.5
9.6x22.5
485
261
1.83
3.08
