CU/XLPE/PVC 0.6/1kV Multicore unarmored cable
shanghai qifan cable co.,ltd.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
CU/XLPE/PVC 0.6/1kV Multicore unarmored cable
shanghai qifan cable co.,ltd.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
From the supplier
Application:
To be used for main power supply, In low voltage distribution power networks, industrial installations, in buildings and operation stations. fixed installation in the ground or in concrete, in the cable trenches or cable, ducts, indoor or outdoor areas, in dry or wet locations.
Construction:
1. Conductor - Plain annealed class 2 stranded (compacted) copper
2. Insulation - Cross linked polyethylene (XLPE)
3. Filler - Non-hygroscopic material
4. Binder tape - Non-hygroscopic material tape
5. Outer sheath - Polyvinyl chloride compound (PVC)
Cross Section：
2C1.5~2C400mm2
3C1.5~3C400mm2
4C1.5~4C400mm2
5C1.5~5C400mm2
2C+E2.5~2C+E400mm2
3C+E2.5~3C+E400mm2
4C+E2.5~4C+E400mm2
Temperature characteristics:
Conductor operating temperature: -15℃~90℃
Min. temperatrue laying condition: 0℃
Conductor emergency operating temperature: 105℃
Conductor short-circuit operating temperature (5s): 250℃
Electrical Characteristics:
Rated voltage: 0.6/1 (1.2) kV
High voltage test: 3.5kV / 5min
Color:
Insulation: According to customer requirements
Outer sheath: Black or orange or according to customer requirements
Standard:
Cable design: IEC 60502-1 or AS/ZNS 5000.1
Conductor: IEC 60228 or AS/ZNS 1125
From the supplier
Application:
To be used for main power supply, In low voltage distribution power networks, industrial installations, in buildings and operation stations. fixed installation in the ground or in concrete, in the cable trenches or cable, ducts, indoor or outdoor areas, in dry or wet locations.
Construction:
1. Conductor - Plain annealed class 2 stranded (compacted) copper
2. Insulation - Cross linked polyethylene (XLPE)
3. Filler - Non-hygroscopic material
4. Binder tape - Non-hygroscopic material tape
5. Outer sheath - Polyvinyl chloride compound (PVC)
Cross Section：
2C1.5~2C400mm2
3C1.5~3C400mm2
4C1.5~4C400mm2
5C1.5~5C400mm2
2C+E2.5~2C+E400mm2
3C+E2.5~3C+E400mm2
4C+E2.5~4C+E400mm2
Temperature characteristics:
Conductor operating temperature: -15℃~90℃
Min. temperatrue laying condition: 0℃
Conductor emergency operating temperature: 105℃
Conductor short-circuit operating temperature (5s): 250℃
Electrical Characteristics:
Rated voltage: 0.6/1 (1.2) kV
High voltage test: 3.5kV / 5min
Color:
Insulation: According to customer requirements
Outer sheath: Black or orange or according to customer requirements
Standard:
Cable design: IEC 60502-1 or AS/ZNS 5000.1
Conductor: IEC 60228 or AS/ZNS 1125
