The standard configuration

1. Fixed height headboard: The height of the headboard is fixed (it does not rise or fall with the adjustment of the bed), so that medical staff can quickly and easily access the head, neck and chest of the patient.

2. Guardrail: Full PP guardrail provides safety protection to prevent patients from falling. Two additional small guardrails at the end of the bed can provide more safety and support for patients to get up and stand.

3. Built-in weighing system: The built-in weighing system is located at the bottom of the bed to prevent damage from impact.

4. Detactable bed surface: the overall bed surface is PP and phenolic resin board structure, easy to move disinfection, backrest can be used for X-ray, the overall design provides patients with a more comfortable experience.

5. Central nursing operating system: Medical staff can control the position of the whole bed through the central operating system to provide patients with a more comfortable and effective position.

6. Column motor system: two lifting column motors realize the lifting of the bed body, TR&ATR function, to ensure the stability of the whole bed.

7. Embedded guardrail operating system: Embedded guardrail operating system can greatly improve the autonomy of patients, patients can adjust the whole bed position according to their own needs.

8. Bedhead and bed tail lock: bedhead and bed tail lock can prevent the bedhead and bed tail from pulling out accidentally in the process of turning or moving the bed body.

9. Image box: the special sliding and positioning structure can easily insert the film box from the side of the bed to the bottom of the bed, and the position of the X-ray film can be adjusted according to the height of the patient.

10. Electric/manual CPR: One-click operation of electric CPR is simple and convenient. Manual CPR can make the backrest return to the emergency position in the case of insufficient power to ensure patient safety. It is equipped with damping device to prevent the backrest from falling instantaneously and can be operated with one hand.

11. Handrail for support station :(optional)

12. Night light :(optional)

13. One-touch chair

14. One-click out of bed

15. Feature lock

16. Battery power display

17. Floor lighting

18. The patient had an emergency stop

19. Central brake

20. Infusion stand jack

21. Four corners for collision avoidance

Technical parameters:

1. Lift or lower the midplane at least 70°

2. Thigh plate lifting ≥25°

3. The minimum height of bed surface is 590mm

4. Bed body lift 590mm ~ 990mm

5. Bed tilt ≥12°

Electrical parameters:

1. Power connection: 220VAC,50/60Hz

2. Input power ≤450VA

3. Protection level IPX4

4. Security classification II

5. Electric shock protection class B application part
