Double flanged Concentric butterfly valve
The supplier hasn’t listed a price. We can get their current prices and MOQ.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
Double flanged Concentric butterfly valve
The supplier hasn’t listed a price. We can get their current prices and MOQ.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
About this product
- Materials: DUCTILE IRON , CAST IRON
- Color: EPOXY POWDER COATED-DARK BLUE
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Hebei, China
About this product
- Materials: DUCTILE IRON , CAST IRON
- Color: EPOXY POWDER COATED-DARK BLUE
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Hebei, China
Product details
| Materials | DUCTILE IRON , CAST IRON |
|---|---|
| Color | EPOXY POWDER COATED-DARK BLUE |
From the supplier
Product Description
Product Description Pressure and temperatureworking pressure
PN10, PN16
testing pressure
shell: 1.5 times rated pressure
seat: 1.1 times rated pressure
working temperature
-10 °C to 80°C (NBR)
-10 °C to 120°C (EPDM)
suitable media
water, oil and gas
Main material list
parts
material
body
cast iron, ductile iron,
seat
EPDM, NBR,PTFE
disc
nickel ductile iron,AI bronze, stainless steel
stem
carbon steel, stainless steel
bushing
PTFE
"O" ring
PTFE
pin
stainless steel
key
stainless steel
