About this product
- Materials: DUCTILE IRON , CAST IRON
- Color: EPOXY POWDER COATED-DARK BLUE
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Hebei, China
About this product
- Materials: DUCTILE IRON , CAST IRON
- Color: EPOXY POWDER COATED-DARK BLUE
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Hebei, China
Product details
| Materials | DUCTILE IRON , CAST IRON |
|---|---|
| Color | EPOXY POWDER COATED-DARK BLUE |
From the supplier
Product Description
double eccentric butterfly valveHigh Performance valves, also known as double eccentric butterfly valves have a stem which is mounted slightly out of the pipeline center and also behind the disc seat. This design leads to minimal wear and low operating torques. Double eccentric design. Disc Rotation Axis. Disc Sealing Surface.
What is the difference between double offset and triple offset butterfly valves?Double Offset Butterfly Valve
This popular valve is also known as a high performance butterfly valve. This valve has two stems offset from the center. This creates a cam action during the application's process.
1st offset: The axis of the shaft is behind the centerline of the sealing point of the disc to seat.
2nd offset: The axis of the shaft is eccentric to the center of the valve/pipe line.
The double offset butterfly valve is generally used in:
Power generation
Pulp and paper
HVAC
Chemical
Oil and gas
Water and wastewater treatment
Shipbuilding
Double offset butterfly valves are available in higher pressures than the zero offset style. The double offset is up to ANSI Class 600 rating in carbon steel, stainless steel, Hastelloy and other body material, with variations of Teflon seats and also Fire Safe design with metal back up seats.
Triple Offset Butterfly Valve
With the triple offset butterfly valve there are three offsets. Two are placed in a similar position to the double offset butterfly valve, while the third offset is the geometry of the seating surface, creating a type of cone shape of the disc and seat. This cone angle, along with the two eccentric shaft offsets, allows the disc to seal against the seat with no friction.
This seat design also allows for uniform sealing, and thus a tight shutoff in a metal seat design. This design is a lower cost, lower torque option (easier to automate), than alternative style metal seated valves.
Triple offsets are generally used in applications similar to gate valves, where a metal seat is required, and tight shutoff and/or quarter turn actuation is desired. Applications like high pressure steam (over 150 PSI), superheated- steam, high temperature gases and oils, high temperature applications are good for this type of valve because a metal seat is required over a soft seat.
The triple offset valve is used in similar industries as the double offset butterfly valve, but in more demanding applications.
If you have any further questions, don’t hesitate to contact us! Our valve team has over 20 years of experience and is happy to help!
