About this product
- Size: 90mm×75mm×25mm
- Color: Blake
- Exports to: Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, EU, Other European Countries
About this product
- Size: 90mm×75mm×25mm
- Color: Blake
- Exports to: Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, EU, Other European Countries
Product details
| Size | 90mm×75mm×25mm |
|---|---|
| Color | Blake |
From the supplier
FGate-lite is a lightweight industrial IoT gateway designed for small industrial projects and edge computing scenarios. Compared with FBox, FBox-lite is smaller in size, has simpler interfaces, and is more cost-effective, meeting the data collection and remote operation.
FEATURES FBox-4G-lite NetworkAccess Ethernet,4G CPU 300MHz ARM9 Storage 128MB Flash+64MB DDR3 Ethernet 1 line of 10M/100M Ethernet Port SD Card / USB Port 1 USB Device 2.0,1 USB Host 2.0 IO Port / Serial Communication Ports COM1:RS232/RS485/RS422,COM3:RS232 Network Frequency Range LTE FDD:B1/B3/B5/B8
LTE TDD:B38/B39/B40/B41
WCDMA:B1/B8
TD-SCDMA:B34/B39
CDMA:BC0
GSM:900/1800MHz RTC Built-in Rated Power <5W Input Voltage DC24V,working range:DC9V-28V PowerProlection Protect from thunder strike and surging Power Interruption Tolerance <3mS Certification CE,RoHS Operating Temperature -10-60℃ Storage Temperature -20-70℃ Environmental Humidity 10-90%RH (Non condensation) Vibration Endurance 10-25Hz(X/Y/Z direction 2G/30minutes) Cooling Natural cooling Dimensions 90mm*75mm*25mm (without antenna) Weight About 220g Endosure Material Powder coated galvanized sheet Transparent Transmission Available VPN Transparent Transmission Available Data Monitoring 300 points Alarm Item 30 points Historical Item 60 points Hisiorical Data Storage Duration 180 days Edge Computing It supports scipts programming Network Protocols It supports over 400 industrial devices protocols Management & Maintenance Support import,export,and remote update of configuration files
