FD SERIES 8 CHANNELS PROFESSIONAL DIGITAL POWER AMPLIFIER
MAIN FUNCTIONS
FD series professional digital power amplifier is designed with 1.5U Lightweight design. High power density, good sound quality and low distortion.
Models with different powers of 2-way / 4-way / 6-way /8-way can cover the power from small to large, and also meet different performance and meeting requirements.
Model Type SizeFD8200FD8300FD8400Output power Output Power(8Ω)8×200W8×300W8×400WOutput power Output Power(4Ω)8×300W8×450W8×600WOutput power (BRIDGE) Bridging Method(8Ω)4×600W4×900W4×1200WOutput Circuit Type Circuit TypeClass DClass DClass DInput Impedance Input Impedance20KΩFrequency Response Frequency Response20Hz~20KHzTHD Total Harmonic Distortion 20Hz ~ 20KHz(8Ω)0.10%Slew Rate Conversion Speed40V/usecSignal-to-noise ratio Signal-to-Noise Ratio103dBDamping coefficient Damping Coefficient(8Ω)＞400Radiator Heat Dissipation MethodHigh/Low Automatic ControlSafeguard Protection MethodDC protection/Overloading protection/Soft start/Short circuit protectionWeight Weight6Kg6Kg6KgDimension Size(mm)480×331×64(1.5U)480×331×64(1.5U)480×331×64(1.5U)Power Range Voltage(115V/230V)Can offer different voltage according to client's requirement.
Regional Voltage Options Available
*Mobile users are advised to long-press on the image and save it to view more details.
From the supplier
FD SERIES 8 CHANNELS PROFESSIONAL DIGITAL POWER AMPLIFIER
MAIN FUNCTIONS
FD series professional digital power amplifier is designed with 1.5U Lightweight design. High power density, good sound quality and low distortion.
Models with different powers of 2-way / 4-way / 6-way /8-way can cover the power from small to large, and also meet different performance and meeting requirements.
Model Type SizeFD8200FD8300FD8400Output power Output Power(8Ω)8×200W8×300W8×400WOutput power Output Power(4Ω)8×300W8×450W8×600WOutput power (BRIDGE) Bridging Method(8Ω)4×600W4×900W4×1200WOutput Circuit Type Circuit TypeClass DClass DClass DInput Impedance Input Impedance20KΩFrequency Response Frequency Response20Hz~20KHzTHD Total Harmonic Distortion 20Hz ~ 20KHz(8Ω)0.10%Slew Rate Conversion Speed40V/usecSignal-to-noise ratio Signal-to-Noise Ratio103dBDamping coefficient Damping Coefficient(8Ω)＞400Radiator Heat Dissipation MethodHigh/Low Automatic ControlSafeguard Protection MethodDC protection/Overloading protection/Soft start/Short circuit protectionWeight Weight6Kg6Kg6KgDimension Size(mm)480×331×64(1.5U)480×331×64(1.5U)480×331×64(1.5U)Power Range Voltage(115V/230V)Can offer different voltage according to client's requirement.
Regional Voltage Options Available
*Mobile users are advised to long-press on the image and save it to view more details.
