About this product
- Materials: steel
- Size: 6000*2400*1300
- Color: red+white
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Others
- Made in: Zhejiang, China
About this product
- Materials: steel
- Size: 6000*2400*1300
- Color: red+white
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Others
- Made in: Zhejiang, China
Product details
| Materials | steel |
|---|---|
| Size | 6000*2400*1300 |
| Color | red+white |
From the supplier
Functions and Features:
Wide width bottom seal model CW-1400FB machine specially designed for heavy duty LDPE and HDPE Liner bags. The technology used here is quite different from the regular smaller width bottom seal machine. The sealing of the film is done by a wire seal system which gives a very strong seal. The cutting is done through a mechanically driven rotary flying knife. The setting of the cutting knife is much simpler compared to the Shear (scissor type) knife used on regular bottom seal machine.
FEATURES:
Using the design with flying knife by servo motor.
The sealing design is heated by two-sided heating wires, to achieve a strong sealing line.
Providing multi producing lines for non-printing bag.
OPTIONAL:
1. punching unit; K sealing etc.
2. Double printing line production
3. Post gusset device
4. Hot slitting unit
5. Hydraulic unwind device
Product Specifications:
Type
CW-800FB
CW-1000FB
CW-1200FB
CW-1400FB
CW-1600FB
Bag making length
200-3000mm
Bag making width
700mm
900mm
1100mm
1300mm
1500mm
Mechanical speed
80pcs/min
80pcs/min
80pcs/min
80pcs/min
70pcs/min
Line speed
60m/min
Film thickness (mm)
(0.04mm-0.15mm)*4
Total power
6.8KW
7.5KW
8KW
9KW
10KW
Machine weight
1680kg
1800kg
2000kg
2100kg
2200kg
Machine dimension
6000X1600
X1300mm
6000X1800
X1300mm
6000X2000
X1300mm
6000X2200
X1300mm
6000X2400
X1300mm
