About this product
- Materials: stainless steel
- Size: 2200*1000*1000
- Color: stainless steel
- Processing material: Other
- Function: Other
- Automatic grade: Semi-Automatic
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Russia, EU, Other European Countries, Others
- Made in: Henan, China
About this product
- Materials: stainless steel
- Size: 2200*1000*1000
- Color: stainless steel
- Processing material: Other
- Function: Other
- Automatic grade: Semi-Automatic
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Russia, EU, Other European Countries, Others
- Made in: Henan, China
Product details
| Materials | stainless steel |
|---|---|
| Size | 2200*1000*1000 |
| Color | stainless steel |
| Processing material | Other |
| Function | Other |
| Automatic grade | Semi-Automatic |
| Certification | CE |
| Power source | Other |
| Composition | Other |
| After-sales service provided | No overseas service provided |
| Material | Other |
| Process | Other |
| Location | factory |
From the supplier
Gaofu automatic feeder screening system negative pressure vacuum feeder manufacturer
Product description
The vacuum feeding machine manufactured by our company is a newly developed product which is the most advanced, ideal vacuum conveying equipment for conveying powder material, granular material, mixture of powder and granular material . It can not only automatically convey a variety of materials to the mixing machine, packing machine, injection molding machine, and grinder but also directly deliver the mixed materials to the mixing machine such as v-type mixing machine, two dimensions mixer and three dimensions mixer. It can reduce the labor intensity and prevent the dust overspill. Pharmaceutical factories and food factories can use it to promote clean production and pass the GMP certification.
Specification
The vacuum feeder machine consists of vacuum pump(oil-free or water-free, ), vacuum hopper, filter(polyester coated, pe, 316L stainless, titanium),compressed air anti-blowing device,pneumatic feeding door device, automatic material level control device, stainless suction nozzle, conveying hose. The whole equipment is well designed and manufactured. Technical parameters Model Motor Power(KW) Conveying Capacity(KG/H) ZKS-1 1.5 200-400 ZKS-2 2.2 300-600 ZKS-3 3 400-1200 ZKS-4 5.5 800-2500 ZKS-6 5.5 1000-3200 ZKS-7 7.5 2000-6000 ZKS-10-6 7.5 2000-6000(Conveying distance is 10 meters) ZKS-20-5 11 1500-5000(Conveying distance is 20 meters)
Note:The data based on when the conveying distance is 4 meters and the materials is flour.
The longer the conveying tube,the lower the capacity,the capacity also has relationship with the characteristic of conveying materials.
Application
About Gaofu
Company Information
Gaofu company founded in 1982, 30 years of development history, gradually improve and integrated industrial chain;Main products include screening machinery, vibration equipment, crushed coal machinery, filtration equipment, dust removal equipment and other industries.With 56 national patents, is a design and production capacity of integrated machinery manufacturing company.
Our Team & Service
Basis service
1.Your sample material can be free analysis in our laboratory.
2.24 hours a week online & quick response within 12 hours.
3.Booking hotel and ticket for customers and Free transportation during visit our factory.
4. Production lead time and delivery time guaranteed.
Customized services
1.Professional R & D team to develop the new products as you requirements.
2.Help high-end customers to develop the local market
3.All packing and shipping can customized as per your requirements.
After-sale services
After customers received the goods,if have any questions or quality problems, Our customer service Dept. will be always available.
Customer Visit
Our customers came from different countries every year.
FAQ
1.Materials name and density that you want to conveying(how's the liquidity of material)?
2.What's the capacity per hour?
3.We also need to know the horizontal distance and vertical high that you want to conveying?
4.What equipment you want to conveying materials to?
