Specification
GENERATOR
Model
JD2000
JD2500
JD3000
Type
Brush Single-Phase
Voltage Regulate
AVR
Frequency Hz
50/60
Rated AC Voltage (V)
110V/120V/220V/230V/240V
Rated AC Output (KVA)
1.5/1.8
2.0/2.2
2.5/3.0
Peak AC Output (KVA)
1.7/2.0
2.2/2.5
2.8/3.5
Power Factor COSφ
1.0
ENGINE
Model
JF168
JF168
JF200
Type
OHV Forced Air-cooled 4-stroke
Bore x Stroke (mm/inch)
68×45/2.68×1.77
68×45/2.68×1.77
68×54/2.68×2.13
Displacement (ml)
163
163
196
Max. output (HP/rpm)
5.5/3600
5.5/3600
6.5/3600
Fuel
Unleaded Gasoline
Fuel Tank Capacity (L/gal)
15/4
Continuous Operating Hours h
13
13
11
Oil
SF or Higher Grade
Oil Capacity (L/gal)
0.6/0.16
Ignition system
T.C.I.
Starting System
Recoil and hand-operated /Electric start
Operating Noise Level (7m) dB(A)
67
STANDARD
FEATURES
Fuel gauge
0
0
0
Engine Switch
0
0
0
Voltmeter
0
0
0
AC Circuit Breaker
0
0
0
AC Socket
0
0
0
OPTIONAL
FEATURES
Pilot Light
+
+
+
Wheel & handle
+
+
+
Hours meter
+
+
+
DC Output
+
+
+
DC Circuit Breaker
+
+
+
PACKAGE DIMENSIONS
Dimensions L×W×H (mm/inch)
600×450×470/23.6×17.7×18.5
Gross Weight (kg/lbs)
41/90.2
42/92.4
52/144.4
Net Weight (kg/lbs)
39/85.8
40/88
48/105.6
20/40FT unit
240/475
NOTE:“0”=with “+”=as request “-”= without Specifications subject to change without notice
