Efficient range extender system: engine thermal efficiency of 45%; The highest efficiency of the motor is 97.44%, and the average efficiency of each power point is 95%, leading internationally;

Ultra lightweight design: Lightweight cylinder head cover, oil pan, turbocharger intake pipe, all aluminum flywheel housing;

Modular design: Machine cooling module and modular intake of air through the crankshaft;

NVH: the surface sound pressure levels of the steady-state range extender at 20kW and 150kW power points are 70.5dBA and 90.2dBA, which are better than industry competitors;

Ultra low fuel cost: adopting advanced technologies such as theoretical air-fuel ratio closed-loop control and multi-point fuel injection to optimize combustion, the engine has better fuel economy, low operating costs, and extremely high cost-effectiveness. Compared to diesel engines, it can save 40.2% in economy;

High reliability: Adhere to the concept of high-quality development, from a technical perspective CAE analysis and experimental verification are considered from multiple dimensions to ensure reliable product quality, B10 has a lifespan of ≥ 1.5 million kilometers;

Ultra low emissions: Methanol is recognized as a clean energy source. Compared to conventional fuels such as gasoline and diesel, methanol combustion is more complete and thorough, and its emissions include CO HC and NOx emissions have significantly decreased, with a reduction of ≥ 95%, achieving near zero emissions.

Item Unit Parameter Type - In-line, four-stroke, liquid-cooled, supercharged and intercooled Rated power/speed KW/rpm 180/2000 Maximum torque/speed Nm/rpm 950/1200-1500 Maximum no-load speed r/min 2200±50 Idle r/min 700±50 Total piston displacement L 5.91 Number of cylinders-bore*stroke mm 4-112*150 Work Order - 1-3-4-2 Direction of rotation (viewed from the flywheel end) - 逆时针 Engine nameplate quality kg 525（No oil or water） Fuel type - Main fuel: M100 methanol Auxiliary starting fuel: 92# gasoline - Without using gasoline auxiliary starting device, standard coolant heating is required to ensure engine starting Exhaust temperature ℃ ≤620 Range extender voltage platform V 600 Range extender rated current A 220 Maximum power generation of range extender KW 150
