Guosheng laser mobile quenching/cladding equipment integrates advanced technology and has powerful functions. The equipment is equipped with a flexible robotic arm that can flexibly rotate 360° to accurately position the workpiece and achieve all-round processing; the equipment integrates quenching and cladding functions. Quenching can greatly enhance the surface hardness and wear resistance of the workpiece; cladding can add specific alloy materials to improve the corrosion resistance and high temperature resistance of the workpiece. Moreover, the equipment has moving rollers, which makes it easy to quickly transfer between different working areas and adapt to diverse processing scenarios. In addition, its operating interface is simple and easy-to-understand, and parameter adjustment is convenient, which ensures stable and efficient processing processes. It is widely used in machinery manufacturing, *, petrochemicals, mold processing, coal and steel industries and other fields.

equipment parameters

project parameters device power 3000W/6000W/12000W laser GS-MAX fiber laser processing range 1900mm robot (customizable) mobile repair device attributes Laser quenching/laser cladding spot size 4*4mm(customizable) Cladding head type Reflecting copper mirror cladding head Cladding head interface LOE/QBH interface cladding efficiency 0.3-1.2㎡/h powder utilization ≥90% alloy powder Iron base, nickel base, cobalt base, copper alloy, cemented carbide, etc.

equipment characteristics

1. Flexible processing

Equipped with a 6-axis robot, it can flexibly rotate 360°, accurately capture all parts of the workpiece, realize all-round quenching and cladding operations, and adapt to the processing needs of complex curved surfaces and special-shaped parts.

2. Functional integration

Integrate the dual functions of quenching and cladding. Quenching strengthens the surface hardness and wear resistance of the workpiece; cladding improves the corrosion resistance and high temperature resistance properties by adding alloys, meeting multi-dimensional process requirements in one stop.

3. Convenient mobility

Moving rollers are installed at the bottom to facilitate rapid transfer in different areas of the workshop, flexibly respond to multi-station and cross-site processing tasks, reduce handling costs, and improve production layout flexibility.

4. Intelligent control

The operating interface is simple, parameter adjustment is convenient, stably controls the processing process, adapts to mold manufacturing, mechanical repair and other scenarios, and helps efficient production.
