HRD97 Series Explosion-proof LED Lightings
WAROM TECHNOLOGY INCORPORATED COMPANY
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
HRD97 Series Explosion-proof LED Lightings
WAROM TECHNOLOGY INCORPORATED COMPANYThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Materials: Copper-free Aluminium Alloy
- Size: 155x155x210mm
- Color: Yellow
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Materials: Copper-free Aluminium Alloy
- Size: 155x155x210mm
- Color: Yellow
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Materials | Copper-free Aluminium Alloy |
|---|---|
| Size | 155x155x210mm |
| Color | Yellow |
Product details
| Materials | Copper-free Aluminium Alloy |
|---|---|
| Size | 155x155x210mm |
| Color | Yellow |
From the supplier
IEC,NEC
◆ Can be used in
Zone 1,2,21,22
Class I,Zone 1,2,22
Division 1, Groups A, B, C, D
◆ Applicable lamp and power(max.20W)
LED : 10W, 20W
◆ Isolated LED lamp compartment, CC-CV (constant current -constant voltage) power controller compartment and terminal compartment; Wind-convection heat dissipation structure
◆ Low-maintenance due to long service life is up to 100,000 operating hours.
Global (IECEx) IECEx (applied for) Gas and dust Ex db eb IIC T6 GbEx tb IIIC T80℃ Db IP66 Europe (ATEX) ATEX (applied for) Gas and dust II 2 G Ex db op IIC T6 Gb II 2 D Ex tb IIIC T80℃ Db IP66 Certificates IECEx; ATEX;CU-TR Conformity to standards EN; IEC Degree of protection IP66 Ambient temperature -40℃~+40℃Material
Copper-free Aluminium Alloy, powder coated surface,
yellow (RAL1021) Toughened glass, stands 4J impact
Weight
3.8kg
Dimensions
155x155x210mm
Lamp specification
Integrated LED, Multiple LED
Lamp power (W)
10W, 20W
Rated voltage
100~277V AC 50/60Hz
Terminal
3 x 1.5~4mm2 (L+N+PE)
Cable entries
M25 x 1.5
Available cable outer diameter
Φ10~Φ14 (mm)
From the supplier
IEC,NEC
◆ Can be used in
Zone 1,2,21,22
Class I,Zone 1,2,22
Division 1, Groups A, B, C, D
◆ Applicable lamp and power(max.20W)
LED : 10W, 20W
◆ Isolated LED lamp compartment, CC-CV (constant current -constant voltage) power controller compartment and terminal compartment; Wind-convection heat dissipation structure
◆ Low-maintenance due to long service life is up to 100,000 operating hours.
Global (IECEx) IECEx (applied for) Gas and dust Ex db eb IIC T6 GbEx tb IIIC T80℃ Db IP66 Europe (ATEX) ATEX (applied for) Gas and dust II 2 G Ex db op IIC T6 Gb II 2 D Ex tb IIIC T80℃ Db IP66 Certificates IECEx; ATEX;CU-TR Conformity to standards EN; IEC Degree of protection IP66 Ambient temperature -40℃~+40℃Material
Copper-free Aluminium Alloy, powder coated surface,
yellow (RAL1021) Toughened glass, stands 4J impact
Weight
3.8kg
Dimensions
155x155x210mm
Lamp specification
Integrated LED, Multiple LED
Lamp power (W)
10W, 20W
Rated voltage
100~277V AC 50/60Hz
Terminal
3 x 1.5~4mm2 (L+N+PE)
Cable entries
M25 x 1.5
Available cable outer diameter
Φ10~Φ14 (mm)
