About this product
- Materials: stainless steel
- Color: same as pictures
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Others
- Made in: Zhejiang, China
About this product
- Materials: stainless steel
- Color: same as pictures
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Others
- Made in: Zhejiang, China
Product details
| Materials | stainless steel |
|---|---|
| Color | same as pictures |
From the supplier
Pressure series Solar Water Heater
This type uses the all glass evacuated solar collector tubes as the heat-absorbing element. The high vacuum degree of the clearance between the outer and inner tube reduces the heat emission which is caused by convection and conduction. The layer films(coating) of the all glass evacuated tubes transfer the sun energy into heat energy. The high absorption and low emittance rate of Jiadele’s layer fils is unique. Depending on the different density between hot water and cold water, a water flowing cycle is created in the tube. Hot water flows automatically upwards while the cold water flows downward. The water in the storage tank will be heated from this natural circulation.
Key Specification
inner tank
stainless steel SUS304-1.2mm
vacuum tube
QB-AL-N/AL-58-1800
outer tank
Galvanized steel
frame
Aluminum alloy
insulation
Polyurethane
reflector
stainless steel
piping connector size
ø22
circulation type
closed loop
welding
laser welding
Electric element
1.5KW
man working pressure
0.6mpa
Type (one)
Area
(m^2)
Vacuum tube
Volume
(Liters)
Grosswet
(kg)
Volume/set
(Cubic meter)
Length
(mm)
DIA(mm)
Qty(pcs)
JDL-SPFS/150J-1
02
2000
58
15
150
103
JDL-SPFS/200J-1
02.5
2000
58
18
200
150
JDL-SPFS/300J-1
2
2000
58
20
250
195
Q:What is your delivery time?
A: 15 working days after receipt of signed PI and down payment.
Q:Which payment methods can you support?
BY T/T: 30% as down payment, balance to be paid against the copy of Bill of Lading.
Q: Are you trading company or manufacturer ?
A: We are factory.
Q:What is your package ways?
A:Generally, standard products with standard package. Extra charge may be required for other custom requirements such as package logo printing.
