About this product
- Materials: Brass
- Size: DN15~25mm
- Color: white，blue
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Hebei, China
About this product
- Materials: Brass
- Size: DN15~25mm
- Color: white，blue
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Hebei, China
Product details
| Materials | Brass |
|---|---|
| Size | DN15~25mm |
| Color | white，blue |
From the supplier
Products Description
The wireless remote water meter can automatically upload the readings of the water meter to the management platform, and the administrator can also send instructions on the platform to control the opening/closing of the water meter valve. It can greatly simplify the charging process in this era of increasing labor costs, and even paperless online charging can be realized.
Products Features
- The whole circuit board uses ultra low power consumption design, powered by high high-capacity lithium battery, and battery life of at least 6 years.
- The module uses a deep dormancy time design that can completely close the wireless module during the deep dormancy period ( not in operation during night time), which drastically helps to reduce power dissipation.
- Module with automatic data storage function when powered down and up, which assures the data won't be lost when powered down.
- The joint of the RF module and the base meter uses the integrated structure with a built-in antenna, which reduces the damage of the antenna.
- AMI function that supports the system can control valve opening or closing in real-time.
- With an anti-magnetic interference function.
- With the battery voltage detection function;
- Support data docking with the Client's management platforms
Technical Specifications
Nominal Diameter mm 15 20 25 Q3/Q1 R100 Overload Flow Rate (Q4) m3 / h 3.125 5 7.875 Permanent Flow Rate (Q3) m3 / h 2.5 4 6.3 Transitional Flow Rate (Q2) m3 / h 0.04 0.064 0.1 Minimum Flow Rate (Q1) m3 / h 0.025 0.04 0.063 Maximum Indication m3 Temperature Class T30/T50/T90 Pressure Class PN10/PN16 Pressure Loss Class 0.63bar Electromagnetic Environment Class E1 Environmental Classification O Protection Class IP68 Installation Direction H Sensitivity to Irregularity Velocity Field Class U10/D5 Battery Lifetime ≥6 yearsOutline Dimensional Drawing
Dimension
Nominal Diameter Length L Length L1 Width B Height H1 Height H2 Connecting Thread mm d D 15 258 165 90 112 184 R1/2 G3/4B 20 299 195 90 112 184 R3/4 G1B 25 345 225 90 114 186 R1 G1 1/4B
