Metal shaper machine BC60100
See what’s includedHide breakdown
- FOB goods (100)
- $900,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $31,500
- Section 301 tariff (25.0%)
- $225,000
- Customs fees (MPF/HMF)
- $1,760
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $900,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $31,500
- Section 301 tariff (25.0%)
- $225,000
- Customs fees (MPF/HMF)
- $1,760
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
Metal shaper machine BC60100
See what’s includedHide breakdown
- FOB goods (100)
- $900,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $31,500
- Section 301 tariff (25.0%)
- $225,000
- Customs fees (MPF/HMF)
- $1,760
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $900,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $31,500
- Section 301 tariff (25.0%)
- $225,000
- Customs fees (MPF/HMF)
- $1,760
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Materials: Metal
- Size: 3640x1575x1780mm
- Color: Blue and White/ Green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
About this product
- Materials: Metal
- Size: 3640x1575x1780mm
- Color: Blue and White/ Green
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
Product details
| Materials | Metal |
|---|---|
| Size | 3640x1575x1780mm |
| Color | Blue and White/ Green |
Product details
| Materials | Metal |
|---|---|
| Size | 3640x1575x1780mm |
| Color | Blue and White/ Green |
From the supplier
1. Shaper workbench can about rotational angle worktable moving structure with lateral and lifting.
2. To planing inclined plane, thereby expanding the scope of use.
3. Feed system of shaper with a cam mechanism, adjust the feed quantity. Change the amount of knife, very convenient.
4. Shaper in knife system overload safety device is installed, when due to careless handling or by external influence and cutting overload when, take the knife itself slipping, nondestructive parts which guarantees the machine to normal operation.
5. The sliding pillow and bed rails and with speed gear pair and the main rail sliding surface, lubrication oil pump has played for circulating lubrication.
6. Shaper with parking brake mechanism, so the speed of transformation. When starting machine tools and parking, the power supply can not be cut off.
Main Specification: Specifications BC60100 Maximum Length(mm) 1000 Horizontal travel of worktable(mm) 800 The max travel from the bottom of Ram to Worktable(mm) 400 Vertical Travel of Worktable(mm) 380 Dimension of Worktable Size(L×W)(mm) 1000×500 Travel of Blade Frame(mm) 160 The max rotatory angel of blade frame(°) ±60° Max Size of Planing tool(W×T)(mm) 30×45 Ram reciprocating times per minutes 15,20,29,42,58,83 Swivel range of worktable mechanic feedings Ten grades of horizontal feedings(mm) 0.3~3 Eight grades of vertical feeding(mm) 0.15~0.5 Rapid feed rate of worktable Horizontal feeding(mm) 3 Vertical feeding(mm/min) 0.5 T-slot in the middle of worktable(mm) 22 Main motor power(kw) 7.5 Overall dimension(L×W×h)(mm) 3640×1575×1780 Net. W/Gross .W(kg) 4870/5150 Machine Details:
From the supplier
1. Shaper workbench can about rotational angle worktable moving structure with lateral and lifting.
2. To planing inclined plane, thereby expanding the scope of use.
3. Feed system of shaper with a cam mechanism, adjust the feed quantity. Change the amount of knife, very convenient.
4. Shaper in knife system overload safety device is installed, when due to careless handling or by external influence and cutting overload when, take the knife itself slipping, nondestructive parts which guarantees the machine to normal operation.
5. The sliding pillow and bed rails and with speed gear pair and the main rail sliding surface, lubrication oil pump has played for circulating lubrication.
6. Shaper with parking brake mechanism, so the speed of transformation. When starting machine tools and parking, the power supply can not be cut off.
Main Specification: Specifications BC60100 Maximum Length(mm) 1000 Horizontal travel of worktable(mm) 800 The max travel from the bottom of Ram to Worktable(mm) 400 Vertical Travel of Worktable(mm) 380 Dimension of Worktable Size(L×W)(mm) 1000×500 Travel of Blade Frame(mm) 160 The max rotatory angel of blade frame(°) ±60° Max Size of Planing tool(W×T)(mm) 30×45 Ram reciprocating times per minutes 15,20,29,42,58,83 Swivel range of worktable mechanic feedings Ten grades of horizontal feedings(mm) 0.3~3 Eight grades of vertical feeding(mm) 0.15~0.5 Rapid feed rate of worktable Horizontal feeding(mm) 3 Vertical feeding(mm/min) 0.5 T-slot in the middle of worktable(mm) 22 Main motor power(kw) 7.5 Overall dimension(L×W×h)(mm) 3640×1575×1780 Net. W/Gross .W(kg) 4870/5150 Machine Details:
About the supplier
Main products: Lathe,Miller,Press brake,Grinding machine,CNC Machining center,Drilling machine,Planing Machine/Slotting Machine,Drilling and Milling Machine,Milling Lathe
- ✓Exhibited at 10 of the last 10 Canton Fairs
- ✓Foreign Trade Company
- ✓Founded 2014
- ✓1 certificate on file
- Exhibited at 10 of the last 10 Canton Fairs
- Foreign Trade Company
- Founded 2014
- 1 certificate on file
