About this product
- Size: 2000kg
- Color: Yellow and other customized colors
- Engine type: Other
- Automatic grade: Other
- Power source: Other
- Walking mode: OtherCrawler
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
About this product
- Size: 2000kg
- Color: Yellow and other customized colors
- Engine type: Other
- Automatic grade: Other
- Power source: Other
- Walking mode: OtherCrawler
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
Product details
| Size | 2000kg |
|---|---|
| Color | Yellow and other customized colors |
| Engine type | Other |
| Automatic grade | Other |
| Power source | Other |
| Walking mode | OtherCrawler |
| Customized | Non-CustomizedCustomizedOther |
From the supplier
Machine Size
Engine
Overall dimension (L*W*H)
3555mm*1300mm*2290mm
Emission Standard
Euro 5/EPA
Axle base(Track length on ground)
1230mm
Engine Brand
Kubota
Track gauge
760mm
Model
D1105
Min.Ground clearance
150mm
Power/Rotation speed
14.1kw(20HP)2000rpm
Swing radius at tail
650mm
Number of cylinder
3
Track System
Working Range
Maximum Travel speed
4km/h
Max.Digging height
3700mm
Width of track shoe
230mm
Max Dumping height
2440mm
Number of track shoe per side
38pcs
Max Digging depth
2400mm
Number of upper role per side
1
Max Vertical diging depth
2025mm
Number of bottom rller per side
3
Max Digging radius
4040mm
Performance Parameter
Min swing radius
1610mm
Standard bucket capacity
0.07m³
Max.Lifting height of blade
240mm
Swing speed
9rpm
Max.Cuting depth of blade
270mm
Max.Grade ability
35°
Boom swing angle(Leff)
75°
Max.Bucket digging force
18KN
Boom swing angle(Right)
45°
Max.Arm digging force
11KN
Hydraulic system pressure
21.5Mpa
Machine weight
2000kg
HT20-3 Performance Parameter Overall dimension(L*W¹H) 4170mm*1300mm*2280mm Standard bucket capacity 0.1m³ Axle base(Track length on ground) 1230mm Swing speed 12rpm Track gauge 1070mm Max.Grade ability 30° Min.Ground clearance 230mm Max.Bucket digging force 15.3KN Swing radius at tail 1180mm Max.Arm diging force 10.5KN Track System Hydraulic system pressure 18Mpa Maximum Travel speed 3.5km/h Machine weight 2000kg Width of track shoe 230mm Arm length 1000mm Number of track shoe per side 38pcs Working Range Number of upper roller per side 0 Max.Digging height 3700mm Number of bottom roller per side 4 Max.Dumping height 2290mm Engine Max.Digging depth 2450mm Emission Standard Euro5/EPA Max.Vertical digging depth 2160mm Engine Model KUBOTA Max.Digging radius 4370mm Power/Rotation speed 14.1kw(20HP)2000rpm Min swing radius 2020mm Optional Engine China Laidong 22.1kw,2300rpm Max.Lifting height of blade 240mm Max.Cutting depth of blade 310mm Number of cylinder 3 Boom swing angle(Lef) Boom swing angle(Right) 45°
