Off-road Utility Vehicle with HVAC assy
Shandong ODES Industry CO.; LTD
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
Off-road Utility Vehicle with HVAC assy
Shandong ODES Industry CO.; LTDThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Size: 3358X1913X1947
- Color: Black Sand
- Exports to: Mainland China, Middle East, USA and Canada, Latin America, Russia, EU, Other European Countries, Others
- Made in: Shandong, China
About this product
- Size: 3358X1913X1947
- Color: Black Sand
- Exports to: Mainland China, Middle East, USA and Canada, Latin America, Russia, EU, Other European Countries, Others
- Made in: Shandong, China
Product details
| Size | 3358X1913X1947 |
|---|---|
| Color | Black Sand |
Product details
| Size | 3358X1913X1947 |
|---|---|
| Color | Black Sand |
From the supplier
TypeEngine type
V-Twin Cylinder 4-Stroke, SOHC, Water Cooling
Number of Valves
8(mechanical adjustment)
Cylinder Diameter
91 mm
Piston Stroke
75mm
Displacement
976cm3
Compression Ratio
10.3:1
Maximum Power
53KW/6500rpm
Transmission Type
CVT
Gearbox Type
Dual Forward Gears (High Speed - Low Speed), ParkingForward, Neutral, and Reverse GearDual range(H/L) with park, neutral and reverse
Overall Length
3358mm
Overall Width
1913mm
Overall Height
1947mm
Cargo Box
1076×1561×260(mm)
Front Gauge
1395
Rear Gauge
1358
Wheelbase
2322
Brake Type
Dual Disc Brake
Tire Size (Front/Rear)
28×10-14/28×10-14
Drive Train
Shaft Driven / Single Auto-Lock Differential
Suspension Type
Front and Rear Independent Suspension Double wishbone independent suspension
Climbing Ability
≥40°
Approach Angle
69°
Departure Angle
75°
Ground clearance
327mm
From the supplier
TypeEngine type
V-Twin Cylinder 4-Stroke, SOHC, Water Cooling
Number of Valves
8(mechanical adjustment)
Cylinder Diameter
91 mm
Piston Stroke
75mm
Displacement
976cm3
Compression Ratio
10.3:1
Maximum Power
53KW/6500rpm
Transmission Type
CVT
Gearbox Type
Dual Forward Gears (High Speed - Low Speed), ParkingForward, Neutral, and Reverse GearDual range(H/L) with park, neutral and reverse
Overall Length
3358mm
Overall Width
1913mm
Overall Height
1947mm
Cargo Box
1076×1561×260(mm)
Front Gauge
1395
Rear Gauge
1358
Wheelbase
2322
Brake Type
Dual Disc Brake
Tire Size (Front/Rear)
28×10-14/28×10-14
Drive Train
Shaft Driven / Single Auto-Lock Differential
Suspension Type
Front and Rear Independent Suspension Double wishbone independent suspension
Climbing Ability
≥40°
Approach Angle
69°
Departure Angle
75°
Ground clearance
327mm
