About this product
- Materials: Aluminum Plastic composite mateiral
- Size: 1220*2440*4
- Color: Black
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, USA and Canada, Russia, EU, Other European Countries, Others
- Made in: Zhejiang, China
About this product
- Materials: Aluminum Plastic composite mateiral
- Size: 1220*2440*4
- Color: Black
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, USA and Canada, Russia, EU, Other European Countries, Others
- Made in: Zhejiang, China
Product details
| Materials | Aluminum Plastic composite mateiral |
|---|---|
| Size | 1220*2440*4 |
| Color | Black |
Product details
| Materials | Aluminum Plastic composite mateiral |
|---|---|
| Size | 1220*2440*4 |
| Color | Black |
From the supplier
PVDF Coating Aluminum Composite Panel for exterior wall caldding
This kind of panel comprises a polyethylene core between two aluminum skin, the front surface is coated with PVDF Kynar paints. Its excellent weather resistance is more suitable for the building's exterior decoration and curtain wall projects.
Raw Materials
Aluminum base material: high strength aluminum alloy sheet
Core: non-toxic low-density polyethylene (LDPE) core
Surface: PVDF Kynar coating
Specification
Width
1220mm, 1250mm, 1500mm
Length
Any size, recommend 2440mm, 3050mm, 4050mm
Panel Thickness
3mm~6mm, recommend 4mm
Alu.Skin Thickness
0.21mm~0.50mm, recommend 0.30mm and 0.40mm
Standard Size
1220mm x 2440mm (4' x 8'); 1500mm x 3050mm (5' x 10')
Colors
Factory's standard 45 colors for reference
Others
Accept custom size and colors too
Physical Parameter
Testing Item
Standard
Result
Unit Weight
ASTM D792
T4mm=5.5kh/m2
Thermal Expansion
ASTM D696
24-28
Thermal Deformation Temperature
ASTM D648
115℃
Thermal Conduction
ASTM D976
0.102kcal/m.hr℃
Impact Resistance
ASTM D732
1.640kgf
Adhesive Strength
ASTM D903
0.77kg/mm
Flexural Elasticity
ASTM D790
4030kg/mm2
Shear Resistance
ASTM D732
2.7 kgf/mm2
Wind-pressure Resistance
ASTM E330
PASSED
Properties Against Water
ASTM E331
PASSED
Advantage
- * Super weather resistance
- * Easy maintenance
- * Easy processing
- * Light weight and colorful surface
- * Non-toxicity and safety
- * Excellent coating property
Applications
Building exterior cladding & curtain wall projects: PVDF coated ACP for outside use, 15 years guarantee time.
Products with factory's full color series for your choice.
Recommend to use panel thickness 4mm, aluminum skin thickness 0.30mm or 0.40mm.
From the supplier
PVDF Coating Aluminum Composite Panel for exterior wall caldding
This kind of panel comprises a polyethylene core between two aluminum skin, the front surface is coated with PVDF Kynar paints. Its excellent weather resistance is more suitable for the building's exterior decoration and curtain wall projects.
Raw Materials
Aluminum base material: high strength aluminum alloy sheet
Core: non-toxic low-density polyethylene (LDPE) core
Surface: PVDF Kynar coating
Specification
Width
1220mm, 1250mm, 1500mm
Length
Any size, recommend 2440mm, 3050mm, 4050mm
Panel Thickness
3mm~6mm, recommend 4mm
Alu.Skin Thickness
0.21mm~0.50mm, recommend 0.30mm and 0.40mm
Standard Size
1220mm x 2440mm (4' x 8'); 1500mm x 3050mm (5' x 10')
Colors
Factory's standard 45 colors for reference
Others
Accept custom size and colors too
Physical Parameter
Testing Item
Standard
Result
Unit Weight
ASTM D792
T4mm=5.5kh/m2
Thermal Expansion
ASTM D696
24-28
Thermal Deformation Temperature
ASTM D648
115℃
Thermal Conduction
ASTM D976
0.102kcal/m.hr℃
Impact Resistance
ASTM D732
1.640kgf
Adhesive Strength
ASTM D903
0.77kg/mm
Flexural Elasticity
ASTM D790
4030kg/mm2
Shear Resistance
ASTM D732
2.7 kgf/mm2
Wind-pressure Resistance
ASTM E330
PASSED
Properties Against Water
ASTM E331
PASSED
Advantage
- * Super weather resistance
- * Easy maintenance
- * Easy processing
- * Light weight and colorful surface
- * Non-toxicity and safety
- * Excellent coating property
Applications
Building exterior cladding & curtain wall projects: PVDF coated ACP for outside use, 15 years guarantee time.
Products with factory's full color series for your choice.
Recommend to use panel thickness 4mm, aluminum skin thickness 0.30mm or 0.40mm.
