QLN1304HP farm tractor Features: 1.The use of flat floors, hanging pedals, side manipulation, 16+8 shuttle shift transmission, and various gear selections can provide a reasonable velocity distribution. 2.240-liter lower large fuel tank, a long operation time; 3.Adopting 13 inch double clutch,high transfer ability reliable effect,operation more comfortable. 4.Adopt independent power output device,steady transmission,large bearing capacity. 5.Using independent oil hydraulic steering system operation,flexible operation,reliable energy saving. 6.Using disc brakes,large braking torque,good braking effecting. 7.Using forced type lifter, reliable use, convenient maintenance. 8.Final drive adopts planetary reduction structure,compact structure,large reduction ratio. 9.New streamlined appearance,greaceful,fashion.

Model

QLN-1304

Engine

Rated power(kw)

95.6

Type

Water-cooled, in-line, four stroke, direct injection

Rotation speed(r/min)

2300

Dimension

Wheel drive

4*4

Minimum using weight (kg)

5050

Overall dimension(mm)

5060*2345*2995

Wheel tread(mm)

Front wheel

1954

Rear wheel

1850

Wheelbase(mm)

2543

Minimum ground clearance(mm)

395

Gearbox

16F+8R

Tire

Front tire

14.9-26

Rear tire

18.4-38

Steering type

Hydraulic power steering

Working device

PTO shaft speed (r/min)

540/1000

Max lifting force(KN)

23

Suspension type

CategoryⅡ3-point linkage
