◆ Total 20 physical signal inputs, including 8 XLR balanced analog input channels with microphone preamps (COMBO), 8 unbalanced 6.5mm TRS analog input channels, 1 stereo USB playback channel, and 1 stereo Bluetooth / Type‑C audio interface input channel.

◆ Total 10 signal outputs, including 6 XLR analog output channels, 1 stereo TRS headphone monitor output, and 1 USB recording output.

◆ 16 mono input buses and 3 stereo input buses, supporting user-customizable routing of physical inputs to input buses.

◆ 12 mixing buses: 6 mono AUX buses, 2 effects buses, 2 mono MTRX matrix output buses, and 1 stereo main output bus.

◆ Input channels support 48V phantom power switching (IN 1–8), analog gain (IN 1–8), digital gain, phase, 0–1000ms delay (total system delay up to 2500ms), pan/balance, level, custom channel labeling, 4-band parametric EQ (switchable between parametric, high-shelf, low-shelf, low-pass), high-pass filter, noise gate, and compressor.

◆ Output channels support 0–1000ms delay (total system delay up to 2500ms), pan/balance, level, custom channel labeling, 4-band parametric EQ (switchable between parametric, high-shelf, low-shelf), high-pass filter, low-pass filter, 31-band GEQ, and compressor.

◆ 2 effects buses with 8 selectable effects: Echo, Reverb, Overdrive, Pitch Shift, Distortion, Flanger, Tremolo, and Chorus.

◆ Input channels feature a gain finder function for quickly locating the optimal gain level.

◆ Supports Bluetooth / 2×2 Type‑C audio interface and USB music playback, scene import/export, and system firmware updates.

◆ 1 TRS headphone monitor output.

◆ Supports LAN connection and external USB WiFi module for web-based control.

◆ Supports saving and recalling of scenes, EQ libraries, GEQ libraries, noise gate libraries, compressor libraries, and effects libraries.

◆ Stores and recalls up to 100 scene presets.
