Genset Standard Configuration

◆ Assembled by Shanghai diesel engine and world famous brand alternator

◆ Radiator and fan with safety guard

◆ Automatic control panel and electricity output switch cabinet

◆ Float battery charger and solenoid switch as standard supply scope

◆ Built-in shock pad

◆ Strong and durable hi-strength base frame

◆ Optional voltage rank: 230V/400V, 220V/380V, 127V/220V, 240V/480V etc.

① Diesel engine

② Alternator

③ Water tank radiator

④ Automatic control panel

⑤ Electricity output switch cabinet

⑥ Built-in shock pad

⑦ Hi-strength Base Frame

Standard Supply Scope

Optional supply scope

SDEC engine:

Shanghai Diesel Engine Co., Ltd., formerly known as Shanghai Diesel Engine Works,is now part of SAIC Group.It is a large-scale listed company engaged in engine R&D and manufacturing and related spare parts production. It has a national technology center and post-doctoral workstation, and an international first-class automatic production line in accordance with Passenger car standard quality management system as well. In the course of nearly 70 years' development, SDEC sells its products all over the world and now has seven series of diesel engine classified as R, H, D, C, E, G and W series with power coverage of 50~1600kW.

Alternator

Alternator adopts brushless synchronization alternator of Leroy-Somer of world famous brand, Leroy-Somer generators are characterized by compact structure, high power density, high efficiency, low reactance, good starting performance, and low failure rate. It can meet the main standards and quality certification requirements on the market. Class H Insulation for whole range. Optimization design by finite element analysis ensure to achieve the best mechanical strength of parts. With Leroy-Somer patented winding protection system, LSA series products are capable of harsh environments and guarantee the product life under extreme working conditions.

◆ Forms: single/double bearing

◆ Protection:IP23(IP44 for option)

◆ Balance: rotator balance is in accordance with ISO1940 and NFC51-112 standard

◆ Overspeed: 2250rpm

◆ Insulation Class: class H

◆ Mechanical Structure: steel base frame

Control System——Deep Sea 6120 Controller

① Power switch

② Power indicator

③ Run button

④ LCD display

⑤ Emergency stop button

It is a self-starting control module at mains failure and is suitable for controlling a single genset. It provides advanced engine testing and protection functions. This module includes an LCD backlit display that clearly displays the engine running status. The module also includes 7-channel input and 6-channel output. Program can be set through the panel and PC software suite.

Parameters:

Deepsea 6120 controller provides such parameters as generator frequency, idling/overspeed, generator voltage, generator current, engine oil pressure, engine water temperature, flexible fuel level, running hour, battery voltage, start/stop failure, emergency stop, failure to meet operating voltage/frequency, charging failure, magnetic sensor signal loss, low battery voltage, three-phase mains voltage and mains frequency.

Circuit breaker

Starting battery

Aosif Soundproof Box-type Genset

Aosif soundproof box-type genset is designed by professional engineers with over a decade of experience.The noise of this kind of genset is controlled at 80-85dB(A) at 1m away, 70~75dB(A) at 7m away, 60~65dB(A) at 15m away.

Weight and Dimension

Our Commitments

★ Products and services all comply with ISO8528 and GB/T2820 manufacturing standards.

★ Management is implemented in strict accordance with ISO9001 Quality Management System and ISO14001 Environmental Management System.

★ All products are CE-certified.

★ All products have passed rigorous factory test to ensure high quality.

★ Product warranty terms are strictly enforced.

★ High-efficiency assembly and production lines ensure on-time delivery.

★ Professional, timely, thoughtful and dedicated services are offered.

★ Favorable and complete original accessories are supplied.

★ Regular and irregular technical training are provided all year round.

★ 24/7/365 Customer Service Center provides fast and effective responses to customers’ service demands.
