From the supplier
Application
The wire is rated at 600V for underground secondary distribution not exceeding 90˚C. It may be directly buried in earth or installed in duct in both wet or dry locations.
Configuration
Black phase insulated conductors cabled with neutral. Neutral will be marked with yellow striping or yellow jacket.
Construction
Conductors: Class B compressed concentric lay stranded 1350 aluminum alloy per ASTM B231 or AA-8000 aluminum alloy per ASTM B800 & B801.
Insulation: Phase conductors in black thermoset cross-linked polyethylene (XLPE). Neutral conductor in black thermoset cross-linked polyethylene (XLPE) identified by yellow striping or full yellow jacket.
Features
Individual cables are UL Listed as USE-2
RUS accepted
Temperature rating of 90˚C dry, wet, and direct burial
Heat, ozone, oil, and chemical resistant
Tear and abrasion resistant
Standards
ICEA S-105-692: 600V Single layer thermoset insulated utility underground distribution cable
UL854: Service Entrance Cables
RUS accepted
ParameterSingle 600V SECONDARY URD
Code Name
Size
Stranding
Insulation Thickness
Nominal Diameter
Approx. Net Weight
Ampacity NEC1
Ampacity ICEA*
Inches
mm
Inches
mm
lb / kft.
kg/km
60°C
75°C
90°C
Direct Buried2
Pole Riser Conduit3
SINGLE CONDUCTOR 600V SECONDARY URD
Cornell
8
7
0.06
1.52
0.26
6.6
34
51
40
44
49
74
36
Princeton
6
7
0.06
1.52
0.3
7.6
47
70
46
56
59
96
47
Mercer
4
7
0.06
1.52
0.35
8.9
67
100
63
72
81
117
60
Clemson
2
7
0.06
1.52
0.41
10.4
97
144
86
100
108
154
82
Kenyon
1
19
0.08
2.03
0.49
12.4
128
190
98
111
124
171
97
Harvard
1/0
19
0.08
2.03
0.52
13.2
154
229
115
133
146
193
112
Yale
2/0
19
0.08
2.03
0.57
14.5
186
277
132
150
162
221
132
Tufts
3/0
19
0.08
2.03
0.62
15.7
225
335
150
172
189
253
155
Beloit
4/0
19
0.08
2.03
0.68
17.3
274
408
173
200
221
290
185
Hofstra
250
37
0.095
2.41
0.75
19.1
329
490
196
228
248
317
199
Gonzaga
300
37
0.095
2.41
0.81
20.6
385
573
224
255
281
349
223
Rutgers
350
37
0.095
2.41
0.85
21.6
439
653
242
278
302
381
248
Dartmouth
400
37
0.095
2.41
0.9
22.9
493
734
259
300
329
410
272
Brown
450
37
0.095
2.41
0.94
23.9
547
814
---
---
---
439
295
Emory
500
37
0.095
2.41
0.98
24.9
601
894
299
344
378
464
318
Duke
600
61
0.11
2.79
1.09
27.7
725
1079
328
377
416
514
355
Furman
700
61
0.11
2.79
1.16
29.5
830
1235
362
416
459
549
386
Sewanee
750
61
0.11
2.79
1.19
30.2
883
1314
368
427
470
567
403
Fordham
1000
61
0.11
2.79
1.34
34
1144
1702
431
494
540
665
492
DUPLEX TRIPLEX QUADRUPLEX 600V SECONDARY URD
Code Name
Phase Conductor
Neutral
Diameter (mils.)
Weight/kft. (lbs.)
Allowable Ampacities*
AWG
Stranding
Insulation
Thickness
AWG
Stranding
Insulation
Thickness
Single Phase
Cond.
Complete
Cable
Direct Burial
In Ducts
DUPLEX 600V SECONDARY URD
Bard
8
7
60
8
7
60
262
524
76
70
55
Clafin
6
7
60
6
7
60
298
596
91
95
70
Delgado
4
7
60
4
7
60
345
690
129
125
90
Everett
2
7
60
2
7
60
403
806
189
187
100
TRIPLEX 600V SECONDARY URD
Erskine
6
7
60
6
7
60
298
644
136
95
70
Vassar
4
7
60
4
7
60
345
745
194
125
90
Stephens
2
7
60
4
7
60
403
870
260
165
120
Ramapo
2
7
60
2
7
60
403
870
290
165
120
Brenau
1/0
19
80
2
7
60
512
1106
409
215
160
Bergen
1/0
19
80
1/0
19
80
512
1106
476
215
160
Converse
2/0
19
80
1
19
80
555
1199
490
245
180
Hunter
2/0
19
80
2/0
19
80
555
1199
540
245
180
Hollins
3/0
19
80
1/0
19
80
603
1302
586
280
205
Sweetbriar
4/0
19
80
2/0
19
80
658
1421
740
315
240
Monmouth
4/0
19
80
4/0
19
80
658
1421
847
315
240
Pratt
250
37
95
3/0
19
80
732
1581
857
345
265
Wesleyan
350
37
95
4/0
19
80
831
1795
1135
415
320
Rider
500
37
95
350
37
95
980
2117
1248
495
395
Fairfield
750
61
110
500
37
95
1188
2860
2304
615
525
QUADRUPLEX 600V SECONDARY URD
Tulsa
4
7
60
4
7
60
345
833
258
120
85
Dyke
2
7
60
4
7
60
403
973
367
155
115
Wittenberg
2
7
60
2
7
60
403
973
375
155
115
Notre Dame
1/0
19
80
2
7
60
512
1236
574
200
150
Purdue
1/0
19
80
1/0
19
80
512
1236
596
200
150
Syracuse
2/0
19
80
1
19
80
555
1340
664
225
170
Lafayette
2/0
19
80
2/0
19
80
555
1340
720
225
170
Swarthmore
3/0
19
80
1/0
19
80
603
1456
805
250
195
Davidson
3/0
19
80
3/0
19
80
603
1456
874
250
195
Wake Forest
4/0
19
80
2/0
19
80
658
1588
1036
290
225
Earlham
4/0
19
80
4/0
19
80
658
1588
1066
290
225
Rust
250
37
95
3/0
19
80
760
1830
1213
325
210
Slippery Rock
350
37
95
4/0
19
80
831
1945
1544
385
305
Wofford
500
37
95
350
37
95
990
2390
2251
467
420
Windham
750
61
110
500
37
95
1200
2890
3266
615
492
