FUHUA Self-Fusing Silicone Rubber Electrical Tape is a high-temperature, arc- and track-resistant tape composed of self-fusing, inorganic silicone rubber with an easy-tear and easy-strip liner. It has high formability, stable insulation. Applicable temperature is from -50°C to 260°C. Meeting an emergency the overload temperature can be up to 300°C. It also helps heat dissipation at the joint. This tape has excellent physical and electrical properties. It can be used in a variety of temperature range without heating and open flame, which is fast and convenient.

Technical Date Sheet

Property

Test Results*

Operating temperature range

-50° C to 250° C

• Optimumworkingtemperature

180° C (10years)

Cold Brittle Point

-50° C

Elongation, Min.

300%

Bond Strength, Min.

50g/mm

Volume resistivity, Min.

1×1013Ω·cm3

Water Absorbtion, Max.

3% By Weight

Dielectric Strength, Min.

20KV/mm

Product Features:

• High temperature resistance:-55℃to250℃
• Excellent insulation, ozone, UV and aging resistant
• Easy to install by hand, no need heating and special tools
• High reliability with excellent physical,chemical and electrical property.
• Self fusing without adhesive, removed without residue,convenient for maintenance
• Flame retardant
• Mechanical vibration reduction

Application Range:

• Insulation protection for subsation,bare parts of the power plant and bus-bar in main network
• Insulation protection for connections of electrical equipment,wire branch ,clamps and terminal of cable head in distribution network
• Especially suitable for substation comprehensive insulation protection.
• Insulation protection for any shape of electrified body,no need free ends
• Insulation and fireproof for large cables and irregular shape conductor
• Insulationprotection for power system in places whrer fire can't be used,like oil field and chemical industry
• Insulation protection and fireproof of cable joint and bus-bar.
