SP65K 65"Interactive E-White Board AIO

Android system hardware configuration

Model

Hi3751V560

CPU

Quad-core A55 quad-core

RAM

2GB/3G

ROM

16GB/32GB

OS

Android 9.0

TV

Cable TV viewing playback function

Support for multimedia file playback through USB

Touch Screen

10-point capacitive touch screen

Support for image multiplication, reduction, and rotation

Applied touch function to various signal sources

The touching function allows controlling the signal source, volume, and other menus through different signal sources

Other Functions

Sleep timer、Power off memory

Remote-keyboard interactive control:

Support for remote control instead of a keyboard to achieve various key functions such as turn on/off, return, menu operation, task preview, channel switching, volume adjustment, quick whiteboard operation, and other functions;

Support selecting any signal source on the main system page

Support for child lock;

Support for wireless Wifi and wired LAN

Support front button to switch on and off the computer with one click

Mainboard input/output interface

USB input

2* (Type-A USB2.0 x2)

TOUCH input

1* (Type-B For HDMI Touch)

Audio input

1*AV audio input

Centralized control interface

1*RS232 serial port

Network Input

1*RJ45 Wired Ethernet port

1* wireless 2.4G Wi-Fi

Video input

2*HDMI

Audio output

1*Headset port

Display

Size

65-inch

Backlight Type

DLED

Backlit Life

50000 hours

Overall dimension (mm)

1429x896

Resolution

4K（3840 x 2160）

Peak Brightness

350cd/㎡

Dynamic Contrast

5000：1

Viewing Angle

H/V：178/178°

Aspect Ratio

16:9

Display Color

10Bit, 16.7M

Refresh Rate

60HZ

Display Protection

4mm fully tempered high explosion-proof glass

Touch Screen

Touch sensor

Infrared sensor recognition touch technology (10 points)

Writing method

Finger, stylus, or other non-transparent objects with a diameter of not less than 5 mm (multi-point 8mm)

Mouse speed

120 points/s

Positioning accuracy

1PI+/-1MM/OFF set/10MM

Touch resolution

4096*4096

Life-span

Theoretical unlimited

Computer response time

≤15ms

Drivers

Drive-free

Electrical performance

Power input

AC 180-240V 50/60Hz

Power Consumption (computer not included)

300W

Rated power of the loudspeaker

Stereo mixed dual-channel CLASS-D amplifier output, rated power:2x10W

（L+R / 8Ω）of THD+N≤10%@1KHz（Audio Input：0.5VRMS）

Smart Conference Whiteboard

Smart Writing Board

Scan the conference content

Wireless Projection

Wireless Projection with one-click

Support Touchback function

low projection latency under 5G

OPS computer

Specification

Supports 80-pin standard Intel protocol OPS computers

OPS Size：195mm*180mm*42mm

I3/i5/i7 four generations or above support 4K-30H, and six generations or above support 4K-60HZ

DDR3/DDR4 4G RAM; SSD 128G（2.5" mechanical hard drive can be added optionally）

Packaging Information（Unit： mm）

PACKING DIMENSION

L1885xH1190xW285

Net weight of the bare machine（KG）

43

The gross weight of the whole machine（KG）

48

Packing List

65-inch interactive conference tablet

1

Remote

1

Stylus

1

Instruction manual / certificate of conformity / warranty card

One for each

Power cord

1

Hanging Bracket

Power cord

Stylus

Remote controller
