About this product
- Size: 3400*1850*2460
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America
About this product
- Size: 3400*1850*2460
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America
Product details
| Size | 3400*1850*2460 |
|---|
From the supplier
Name Weight Name
SWAN3WP-500
Machine
Body
Foot
Cun
Diemensions
※1
Total LengthLength（mm）
3400
Total WidthWidth（mm）
1850
Total HeightHeight(mm）
2460
WheelbaseWheelbase(mm）
1570
Wheel TrackTread(mm）
1540
Effective Clearance HeightEffective Height(mm）
1100
Minimum Clearance HeightMinimum Ground Height(mm）
1055
MassWeight（kg）
880
Inlet
Support
Engine
TypeType
Water-Cooled 4-Stroke 3-Cylinder Vertical Diesel Engine3-cylinder,4-stroke, vertical air-cooled diesel engine
NameName
3TNM72-AMW
Engine DisplacementDisplacement（L）
0.904
Rated PowerRated Power（KW/rpm）
17.1/3600
Fuel Tank CapacityFuel Tank Capacity（L）
20
Starting MethodStarting Method
Electric StartMotor Starter
Row
Running
Part
Moving System
TypeType
4WD·4WS
Operating ModeOperation Mode
Full Hydraulic Power Steering SystemConstant Pressure Hydraulic Power Steering Gear
Transmission StagesSpeed Variable shift
HST(Continuously VariableCvt) Auxiliary Transmission 2Section HST（CVT) Auxiliary：2 Shift
Travel SpeedMoving Speed（km/h)
MobilityOff-working Speed ：0-11 SpreadingWorking Speed ：0-4.2
Brake (also serves as parking brake)Brake System（Dual For Parking）
Wet Multi-Plate MechanicalWet Multi-Disc Mechanical Brake
Tires (Front·Rear)Tyre(Front.Rear)
120/90-26 6PR(Tire PressureTyre Pressure 250Pa）
BatteryBattery
12V45Ah
Medicine Tank CapacityPesticide Tank Capacity（L）
500(MaximumMaximum 545）
Agitation MethodPesticide Stirring Method
Jet AgitationSpout Stirring
Spray
Mist
Use
pump
Spray Pump
NameModel
HS-340
TypeType
Three-Cylinder Plunger Pump3-Cylinder Piston Pump
Rotation SpeedSpeed（rpm)
800
Rated FlowRated Flow（L/min）
62
Maximum PressureMax.Pressure（MPa)
1.5
※2 Spray Operating PressureSpray Working Pressure（MPa)
1.0-1.5
Protect
Remove
Mount
Position
Part
Spray Boom Structure
Boom TypeArm Type
Dual-Arm, Electronic Open-Close, Electric Hydraulic Up-Down Adjustment
Double Arm,Electric Spreading and Closing, Elect-hydraulic Up-Down Adjusting
Nozzle TypeSprayer Nozzle Type
Ceramic Conical Nozzle • Side Nozzle • Anti-drip Spray HeadCeramic Conical Nozzle, Side Nozzle, Drip-proof Nozzle
Number of NozzlesNumber of Nozzlew
Ceramic Cone NozzleNumber of Ceramic Conical Nozzle
21
Side NozzleSide Nozzle
2Set (Spray Head:4Pieces)2 sets,4 pcs
Telescopic SectionsNumber of Stretch Joint
3
Spray WidthSpraying Width（m）
13(Including Side SprayIncluding Side Nozzle）
Nozzle Height from GroundNozzle Height（mm）
460-1390
Mist Cone Angle (degree)Fog Con-Angle(Degree)
80
Spray AmountSpraying Volume
0.7（2mpa）
IntervalNozzle Gap（mm）
350
