About this product
- Materials: cast iron
- Size: DN100
- Color: bule
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU, Other European Countries, Hong Kong China, Macao China and Taiwan China
- Made in: Tianjin, China
About this product
- Materials: cast iron
- Size: DN100
- Color: bule
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU, Other European Countries, Hong Kong China, Macao China and Taiwan China
- Made in: Tianjin, China
Product details
| Materials | cast iron |
|---|---|
| Size | DN100 |
| Color | bule |
Product details
| Materials | cast iron |
|---|---|
| Size | DN100 |
| Color | bule |
From the supplier
Specifications:
Nominal pressue (MPa)
1.0
1.6
Nominal diameter(mm)
50-1000
50-1000
Test pressure
Shell
1.5
2.4
(MPa)
Seal
1.1
1.76
Applicable temperature
150
Applicable medium
Fresh water, Sewage, Sea water, Air, Vapor, Food, Medicine, Oils, Acids,
Alkalis, etc.
Operating mode
manual, worm gear, pneumatic, electric, etc.
Standards:
Design & Manufacture
Flange Connection
Face to Face Dimension
Test & Inspection
API 594
DIN PN10/16/25
API594
API 598
Material:
body Cast Iron, Ductile Iron, Carbon Steel, Stainless Steel Plate Ductile Iron, Carbon Steel, Stainless Steel Spring Stainless Steel Hinge Pin Stainless Steel Plug carbon steel Body Bearing PTFE Spring Bearing PTFE Stop Pin Stainless Steel Eye Bolt Carbon Steel Body Seat NBR, EPDM, Viton, NeopreneFrom the supplier
Specifications:
Nominal pressue (MPa)
1.0
1.6
Nominal diameter(mm)
50-1000
50-1000
Test pressure
Shell
1.5
2.4
(MPa)
Seal
1.1
1.76
Applicable temperature
150
Applicable medium
Fresh water, Sewage, Sea water, Air, Vapor, Food, Medicine, Oils, Acids,
Alkalis, etc.
Operating mode
manual, worm gear, pneumatic, electric, etc.
Standards:
Design & Manufacture
Flange Connection
Face to Face Dimension
Test & Inspection
API 594
DIN PN10/16/25
API594
API 598
Material:
body Cast Iron, Ductile Iron, Carbon Steel, Stainless Steel Plate Ductile Iron, Carbon Steel, Stainless Steel Spring Stainless Steel Hinge Pin Stainless Steel Plug carbon steel Body Bearing PTFE Spring Bearing PTFE Stop Pin Stainless Steel Eye Bolt Carbon Steel Body Seat NBR, EPDM, Viton, NeopreneAbout the supplier
