About this product
- Materials: Q235
- Color: Customizable
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Henan, China
About this product
- Materials: Q235
- Color: Customizable
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Henan, China
Product details
| Materials | Q235 |
|---|---|
| Color | Customizable |
Product details
| Materials | Q235 |
|---|---|
| Color | Customizable |
From the supplier
XL Series Spiral Sand Washers can wash and sever the powder and dirt. Its novel seal structure and adjustable overflow barrier plus reliable driving system make an effective result of washing.
CAPACITY
20-350t/h
MAX FEEDING SIZE
≤10mm
RAW MATERIALS
Between fine-grained and coarse-grained materials
APPLICATION
Wash, classify, rid impurities, and coarse from the fine in the industries of highway, hydropower, construction.
INTRODUCTION OF XL SERIES SPIRAL SAND WASHERXL Series Spiral Sand Washers can wash and separate the soil and foreign material in the sand.Its novel structure,adjustable overflow dam baffle and reliable arrangement can make sure the result of wash. XL Series Spiral Sand Washers is widely used to wash, classify, rid impurities, and choose the coarse from the fine in the industries of highway, hydropower, construction, and so on. It is better to wash construction and road sandstone.
TECHNOLOGY ADVANTAGES OF XL SERIES SPIRAL SAND WASHERXL Series Spiral Sand Washer has the characteristics of reasonable structure, convenient maintenance, high output, low power consumption, and high degree of cleanness.
Its novel sealed structure, totally-enclosed oil-bath transmission system, and adjustable overflow slice ensure the characteristics of high efficiency, durability, cleanness, and good dehydrating effect, and reliable product size.
PRODUCT DATATechnical Data of XL series Spiral Sand Washer
Model XL508 XL610 XL762 XL915 2XL915 XL1115 2XL1115 Screw Diameter(mm) 508 610 762 915 915 1115 1115 Length of Tub(mm) 6705 7225 7620 7585 7585 9782 9782 Max Feed Size(mm) ≤ 10 ≤ 10 ≤ 10 ≤ 10 ≤ 10 ≤ 10 ≤ 10 Capacity (t/h) 20 40-50 50-75 100 200 175 350 Speed of Screw (r/min) 38 32 26 21 21 17 17 Motor Power ( kw) 5.5 7.5 11 11 2×11 15 2×15 Water Consumption(t/h) 6-60 6-63 9-63 10-80 20-160 20-150 40-300 Overall Dimensions(mm) (L×W×H) 8000×2343×1430 8000×2050×1400 8545×2650×3862 8500×2810×3600 8420×3765×3960 10970×3945×4720 10970×5250×4720 Weight(t) 2.67 3.80 5.23 6.27 11.11 10.18 17.94From the supplier
XL Series Spiral Sand Washers can wash and sever the powder and dirt. Its novel seal structure and adjustable overflow barrier plus reliable driving system make an effective result of washing.
CAPACITY
20-350t/h
MAX FEEDING SIZE
≤10mm
RAW MATERIALS
Between fine-grained and coarse-grained materials
APPLICATION
Wash, classify, rid impurities, and coarse from the fine in the industries of highway, hydropower, construction.
INTRODUCTION OF XL SERIES SPIRAL SAND WASHERXL Series Spiral Sand Washers can wash and separate the soil and foreign material in the sand.Its novel structure,adjustable overflow dam baffle and reliable arrangement can make sure the result of wash. XL Series Spiral Sand Washers is widely used to wash, classify, rid impurities, and choose the coarse from the fine in the industries of highway, hydropower, construction, and so on. It is better to wash construction and road sandstone.
TECHNOLOGY ADVANTAGES OF XL SERIES SPIRAL SAND WASHERXL Series Spiral Sand Washer has the characteristics of reasonable structure, convenient maintenance, high output, low power consumption, and high degree of cleanness.
Its novel sealed structure, totally-enclosed oil-bath transmission system, and adjustable overflow slice ensure the characteristics of high efficiency, durability, cleanness, and good dehydrating effect, and reliable product size.
PRODUCT DATATechnical Data of XL series Spiral Sand Washer
Model XL508 XL610 XL762 XL915 2XL915 XL1115 2XL1115 Screw Diameter(mm) 508 610 762 915 915 1115 1115 Length of Tub(mm) 6705 7225 7620 7585 7585 9782 9782 Max Feed Size(mm) ≤ 10 ≤ 10 ≤ 10 ≤ 10 ≤ 10 ≤ 10 ≤ 10 Capacity (t/h) 20 40-50 50-75 100 200 175 350 Speed of Screw (r/min) 38 32 26 21 21 17 17 Motor Power ( kw) 5.5 7.5 11 11 2×11 15 2×15 Water Consumption(t/h) 6-60 6-63 9-63 10-80 20-160 20-150 40-300 Overall Dimensions(mm) (L×W×H) 8000×2343×1430 8000×2050×1400 8545×2650×3862 8500×2810×3600 8420×3765×3960 10970×3945×4720 10970×5250×4720 Weight(t) 2.67 3.80 5.23 6.27 11.11 10.18 17.94About the supplier
Main products: Sand-making equipment,Other Large Machinery u0026 Equipment
