About this product
- Size: 310*240*290
- Color: blue
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Fujian, China
About this product
- Size: 310*240*290
- Color: blue
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Fujian, China
Product details
| Size | 310*240*290 |
|---|---|
| Color | blue |
From the supplier
OPERATING CONDITIONS
l Liquid temperature up to 60℃
l Hot water type up to 100℃
l Ambient temperature up to 40℃
l Total Suction lift up to 9m
l Continuous duty
l Ph: 6.5 to 8.5
PUMP
l Pump Body: Cast Iron
l Impeller: Brass
l Mechanical Seal: Carbon / Ceramic / Stainless Steel
MOTOR
l Single Phase lHeavy Duty Continuous Work
l Motor Housing: Aluminum lShaft: AISI304
l Insulation: Class B / Class F lProtection: IPX4
l Cooling: External Ventilation
ADVANTAGES & FEATURES
l Pressrue and flow switch control automatically
l Pump bodyinsert of stainless sheet 304
l Intelligent control:Pump can supply stabilized waterflow by automatically running. Throughthe water flow and water pressure data collectedby flow switch and pressure switch, electronicunit control the pump running/stop, solve thefrequently starting problems under low water flow, and completely inhibit frequently starting if water flows lower than 0.3m3/h.
l Time delay start: 3 seconds delay on startup toprevent electric transient surge
l DryRun protection:Pump shut down if no water past pump inlet after running 6 minutes,when there is water flow pastpump inlet, pump restart.
l Scale prevention: Pump will automatically run 10 seconds for scale prevention once per 3 days among outage period.
l Electronic switch: Long service life, and eliminate the "da da“noise caused by mechanical pressure switch
l Double check valve,make reliable life time
BRIEF INFORMATION:
- Brand Name : JIANMING
- Model Name: YDTP series
- Products Type: Self-priming peripheral pump
- Place of Origin: Fuan, China
- Color: Customer Required
- Fuel: Electricity
- Supply Ability: 100000/Pieces per Month
- Packaging & Delivery: Strong Carton with Foam Packing , Export Standard
- Place of Origin: Fujian, China
