About this product
- Size: 850x440x680
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America
About this product
- Size: 850x440x680
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America
Product details
| Size | 850x440x680 |
|---|
Product details
| Size | 850x440x680 |
|---|
From the supplier
Model
Model
ZS1105NM
Type
Type
Single Cylinder, Horizontal, Four-Stroke
Single-cylinder Horizontal Four-stroke
Combustion Method
Combustion system
Direct Injection
Direct injection
Cylinder Diameter x Stroke (mm）
Borexstroke(mm)
105×115
Compression Ratio
Compression ratio
17±1
1Hourly Power kW/r/min
1-hour rated output(kw/r/min)
13.3/2200
12Hourly PowerkW/r/min
12-hour rated output(kw/r/min)
12.1/2200
Fuel Consumption Rate
Specific fuel consumption(g/kw h)
≤250.2
Oil Consumption Rate
Specific lube oil consumption(g/kw h)
≤2.72
Cooling Method
Cooling system
Condenser Cooling
Radiator
Lubrication Method
Lubrication system
Pressure & Splash Combined
Combined pressure and Splashing
Starting Method
Starting method
Electric Start
Electric start
Net Weight (kg)
Net weight(kg)
≤155
Power Output Type
Method of power output
Flywheel End Output
Output of flywheel end
External Dimensions（mm）
Overall dimensions(mm)
850×440×680
From the supplier
Model
Model
ZS1105NM
Type
Type
Single Cylinder, Horizontal, Four-Stroke
Single-cylinder Horizontal Four-stroke
Combustion Method
Combustion system
Direct Injection
Direct injection
Cylinder Diameter x Stroke (mm）
Borexstroke(mm)
105×115
Compression Ratio
Compression ratio
17±1
1Hourly Power kW/r/min
1-hour rated output(kw/r/min)
13.3/2200
12Hourly PowerkW/r/min
12-hour rated output(kw/r/min)
12.1/2200
Fuel Consumption Rate
Specific fuel consumption(g/kw h)
≤250.2
Oil Consumption Rate
Specific lube oil consumption(g/kw h)
≤2.72
Cooling Method
Cooling system
Condenser Cooling
Radiator
Lubrication Method
Lubrication system
Pressure & Splash Combined
Combined pressure and Splashing
Starting Method
Starting method
Electric Start
Electric start
Net Weight (kg)
Net weight(kg)
≤155
Power Output Type
Method of power output
Flywheel End Output
Output of flywheel end
External Dimensions（mm）
Overall dimensions(mm)
850×440×680
About the supplier
Main products: Generating Sets,Diesel engine,Diesel Generators,Engine Water Pump Machine Sets,AC u0026 DC electrical machine,Diesel Engines,Other Power Machinery and Electric Power
- ✓Exhibited at 10 of the last 10 Canton Fairs
- ✓Manufacturer
- ✓Founded 1952
- Exhibited at 10 of the last 10 Canton Fairs
- Manufacturer
- Founded 1952
