Looking for a low-bed trailer for sale that delivers strength, stability, and flexibility for transporting heavy machinery? Our 13-meter, Three-Axle Low-Bed Trailer is built for demanding transport tasks, especially in construction, mining, and infrastructure projects.

The trailer is 8,765 mm long and 3,000 mm wide, giving you plenty of space for oversized loads. Its platform height is 1,255 mm, and the fifth wheel height can be adjusted to match your tractor, ensuring better road clearance and smoother coupling.

With a payload capacity of 40,000 kg and a tare weight of about 10,400 kg, this model offers a strong balance of durability and load efficiency. It comes equipped with three FUWA 13T axles, a reinforced mechanical suspension system, and 12 high-quality 12R22.5 tires fitted on steel rims—all contributing to safe and stable transport, even in tough working environments.

Painted with a protective primer and topcoat, this low-bed trailer is built to resist corrosion and harsh weather conditions. Color customization is available based on your preferences.

Trailer Parameters

Overall Dimension (mm) Length×width×height:13,000x3,000xH1 mm（The height will be adjusted according to the tractor specification） Working platform Length×width×height:8,765x3,000x1,255 mm Fifth Wheel Height (mm) The height will be adjusted according to the tractor's specifications Tare Weight (kg) 10,400 kg（±5%） Payload (kg) 40,000 kg（±5%） Gross weight (kg) 50,400 kg（±5%） Tire Type: 12R22.5, equipped with 12 pieces per chassis, a famous brand from China, optioned by the factory. Rim Type: 9.0-22.5, equip 12pcs per chassis Axle FUWA 13T, 3 sets, without ABS Suspension 3-axles enforced mechanical suspension Landing Gear 30T Kingpin JOST 3.5”, exchanged Brake System 30/30 type on rear two axles, WABCO brake valve ABS Non Electrical System 24V, LED lamp Spare Tire Carrier Equip 1 set per chassis Tool Box 1 set Paint Primer + top coat, polyurethane paint Color By the customer’s requirement.
