HGHY Pulp Molding Auto Thermoforming High Quality IP Machine production line
HGHY Pulp Molding Pack Co., Ltd.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
HGHY Pulp Molding Auto Thermoforming High Quality IP Machine production line
HGHY Pulp Molding Pack Co., Ltd.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
From the supplier
APPLICATION
Application like high end electronic products packaging, cosmetics products packaging , High-end Liquor packaging, high added value art and crafts packaging etc.
MAIN FEATURES
With auto thermoforming high quality IP machine as the main system, our pulp molding production line has the following features:
- Energy saving and eco-friendly
- High reliability and uniform of production running
- All-in-one design with fully automatic
OUR ADVANTAGES
Efficient
Small drafting angle to 0°, small round corner to R0.3;
Adjustable
Precise fine tuning for all aspects like distance, pressure and temerature;
Maturity
Successfully developed and put into use by customers as early as 2002;
Adeptness
Set of complex papermaking and mold supporting and efficient production in one.
Main Specifications
Model.
ZJWD-9575 / ZJWD-14375
Structure
Forming Station x1,
Hot pressing Station x1,
with Product Discharge Station and Automatic Control System.
Platen Size
950 x 750 mm / 1430 x 750 mm
Forming Type
Reciprocating
Heating Type
Electricity or Thermal Oil
Max. Pressure
35 Ton / 55 Ton, by Hydraulic Cylinder
Max. Product Height
100 mm
Product Transfer TypeUpper Platen Move Back And Forth Along the Guide RailHeating Plate DivisionDepend on ProductsControl By
PLC + Touchscreen
Designed Capacity
Depends on Products
Remarks
* The above specification is for reference only. As technology is developed continuously, data will be updated from time to time.
* Pulp molding equipments are non-standard equipments. We offer customized solution according to your specific requirements.
* Welcome to contact us at anytime. Our professional team will provide more effective help and supports for you.
