APPLICATION

Mainly suitable for the production of bigger height pulp molded trays like punnet, shoe insert, cup holder, wine bottle tray, protective carriers, especially with higher volume in demand.

 MAIN FEATURES

Pulp molding production line with reciprocating egg tray/carton machine as the main system has the following features:

- Rotary forming specially designed for higher products
- Flexible adapt to different height of products
- Match with energy-saving single-pass dryer
- Diversified after-processing options

 OUR ADVANTAGES

Professional

Replace conventional manual production, improve efficiency and get reliable output;

Advanced

Brand new technology to adapt for all the quick changing demands from plastic-free trend;

Balance

Years of perfecting, enables to balance the machine investment costs and production costs to become win-win;

Durability

The earliest equipments which put into customer use has been over 10 years, still are in normal production.

 MAIN SPECIFICATIONS

Model.

XZ3-19542

Structure

8 Faces Rotary Forming
1 Faces Pick-and-Place Transfer
With Forming Mold Washing and Product Flushing
 Adjustable Mold Clamping Height

Platen Size

1950 x 420 mm

Forming Type

Rotary Forming

Max. Product Height

120 mm

Matching Dryer

Single Layer Dryer

Control By

PLC + Touchscreen

Designed Capacity

200 - 400 KG/hr

Remarks

* The above specification is for reference only, due to continuous technology development, data will be updated from time to time.
* Pulp molding equipments are non-standard equipments, we are able to provide customized solution according to specific requirements from customer.
* Welcome to contact us anytime, our professional team will provide more effective help and supports for you.
