From the supplier
Product descriptions
One-piece frame
Quick change system
Uncoiler: 3 Tons
Forming stations: 24
Electric cabinet: Siemens Control System
Cantilever console: Siemens touch screen
Main motor power: 7.5*2KW, 220/380V, 50/60 HZ, 3 Phase
Punching: hydraulic punching, 40/60 two sets of mould
External hydraulic station: 5.5KW, 220/380V, 50/60 HZ, 3 Phase, accumulator and Air cooling
Thickness: HZ-40: 0.4-0.6mm
HZ-60: 0.5-1.0mm
Feeding type: 1.5 KW servo feeding (Siemens), more than 100 times per minute
Cutting type: 1.5KW fly saw cutting with servo motor (Siemens), 3 KW fly saw cutting head
Forming speed: 15m/min, 12m/min (with punching)
Drive type: gear transmission system
Lubricating cooling system
Technical process
Uncoiler---Hydraulic punching---Servo feeding---Roll forming---fly saw cutting with servo motor---Run out
From the supplier
Product descriptions
One-piece frame
Quick change system
Uncoiler: 3 Tons
Forming stations: 24
Electric cabinet: Siemens Control System
Cantilever console: Siemens touch screen
Main motor power: 7.5*2KW, 220/380V, 50/60 HZ, 3 Phase
Punching: hydraulic punching, 40/60 two sets of mould
External hydraulic station: 5.5KW, 220/380V, 50/60 HZ, 3 Phase, accumulator and Air cooling
Thickness: HZ-40: 0.4-0.6mm
HZ-60: 0.5-1.0mm
Feeding type: 1.5 KW servo feeding (Siemens), more than 100 times per minute
Cutting type: 1.5KW fly saw cutting with servo motor (Siemens), 3 KW fly saw cutting head
Forming speed: 15m/min, 12m/min (with punching)
Drive type: gear transmission system
Lubricating cooling system
Technical process
Uncoiler---Hydraulic punching---Servo feeding---Roll forming---fly saw cutting with servo motor---Run out
