About this product
- Automatic grade: OtherNon Automation
- Customized: Non-CustomizedOtherCustomized
- Power source: OtherGasoline
- Walking mode: WheeledCrawlerOther
- Engine type: OtherDiesel Engine
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Changhzou, Jiangsu, China
About this product
- Automatic grade: OtherNon Automation
- Customized: Non-CustomizedOtherCustomized
- Power source: OtherGasoline
- Walking mode: WheeledCrawlerOther
- Engine type: OtherDiesel Engine
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Changhzou, Jiangsu, China
Product details
| Automatic grade | OtherNon Automation |
|---|---|
| Customized | Non-CustomizedOtherCustomized |
| Power source | OtherGasoline |
| Walking mode | WheeledCrawlerOther |
| Engine type | OtherDiesel Engine |
Product details
| Automatic grade | OtherNon Automation |
|---|---|
| Customized | Non-CustomizedOtherCustomized |
| Power source | OtherGasoline |
| Walking mode | WheeledCrawlerOther |
| Engine type | OtherDiesel Engine |
From the supplier
Cummins EFI engine (in compliance with National III emission regulations) is powerful, efficient, energy-saving, reliable and durable; advanced negative flow hydraulic system is comfortable to operate, high working efficiency, and excellent cost performance; full power control, four power modes adapt to different working conditions;ECM high-precision control of fuel injection, significantly reducing fuel consumption; full three-dimensional modeling and finite element analysis technology ensure the reliability and stability of structural components.
Operating weightKg
47500
Standard bucket capacity (rock bucket)Standard bucket capacitym3
2.2
Overall lengthmm
12035
Overall width (600mm track shoe) Overall width (600mm track shoe)mm
3340
Overall heightmm
3752
Turntable width Trunnable widthmm
3215
Cabin height above groundmm
3314
Maximum traction Max. tractionKN
383
Traveling speed (H/L)Km/hr
4.6/2.8
Swing speedrpm
8.6
GradeabilityDegree(%)
35（70%）
Maximum mining radiusKgf/cm2
0.8
Maximum mining radius11757 mm
Ground maximum digging radius11562mm
Maximum mining depth7442 mm
Maximum ground excavation depth (2438mm horizontal) Ground maximum digging depth7283 mm
Maximum vertical digging depth6084 mm
Maximum digging height11173 mm
Maximum unloading height7662 mm
Minimum front radius of gyration Min. front turning radius5041 mm
Bucket digging force290 KN
Stick digging force251 KN
From the supplier
Cummins EFI engine (in compliance with National III emission regulations) is powerful, efficient, energy-saving, reliable and durable; advanced negative flow hydraulic system is comfortable to operate, high working efficiency, and excellent cost performance; full power control, four power modes adapt to different working conditions;ECM high-precision control of fuel injection, significantly reducing fuel consumption; full three-dimensional modeling and finite element analysis technology ensure the reliability and stability of structural components.
Operating weightKg
47500
Standard bucket capacity (rock bucket)Standard bucket capacitym3
2.2
Overall lengthmm
12035
Overall width (600mm track shoe) Overall width (600mm track shoe)mm
3340
Overall heightmm
3752
Turntable width Trunnable widthmm
3215
Cabin height above groundmm
3314
Maximum traction Max. tractionKN
383
Traveling speed (H/L)Km/hr
4.6/2.8
Swing speedrpm
8.6
GradeabilityDegree(%)
35（70%）
Maximum mining radiusKgf/cm2
0.8
Maximum mining radius11757 mm
Ground maximum digging radius11562mm
Maximum mining depth7442 mm
Maximum ground excavation depth (2438mm horizontal) Ground maximum digging depth7283 mm
Maximum vertical digging depth6084 mm
Maximum digging height11173 mm
Maximum unloading height7662 mm
Minimum front radius of gyration Min. front turning radius5041 mm
Bucket digging force290 KN
Stick digging force251 KN
