Steel Bar Bender Gw42d-4
CHENGDU GUTE MACHINERY WORKS CO.,LTD
See what’s includedHide breakdown
- FOB goods (100)
- $120,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $4,200
- Section 301 tariff (25.0%)
- $30,000
- Customs fees (MPF/HMF)
- $566
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $120,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $4,200
- Section 301 tariff (25.0%)
- $30,000
- Customs fees (MPF/HMF)
- $566
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
Steel Bar Bender Gw42d-4
CHENGDU GUTE MACHINERY WORKS CO.,LTDSee what’s includedHide breakdown
- FOB goods (100)
- $120,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $4,200
- Section 301 tariff (25.0%)
- $30,000
- Customs fees (MPF/HMF)
- $566
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $120,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $4,200
- Section 301 tariff (25.0%)
- $30,000
- Customs fees (MPF/HMF)
- $566
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Materials: Inside gear is casting steel, 10 years warranty
- Size: 810X760X860
- Color: BLACK+YELLOW
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia
- Made in: Sichuan, China
About this product
- Materials: Inside gear is casting steel, 10 years warranty
- Size: 810X760X860
- Color: BLACK+YELLOW
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia
- Made in: Sichuan, China
Product details
| Materials | Inside gear is casting steel, 10 years warranty |
|---|---|
| Size | 810X760X860 |
| Color | BLACK+YELLOW |
Product details
| Materials | Inside gear is casting steel, 10 years warranty |
|---|---|
| Size | 810X760X860 |
| Color | BLACK+YELLOW |
From the supplier
Advantage:
1.The latest heavy-duty gear box assembly,spindle is a maintenance free
2.Column and spool adopt high quality alloy steel,high temperature quenching treatment,higher hardness,more wear-resisting
3.Increase heavy of disc and square steel,Never deformation,bend bar more accurately
4.Enclosed electric cabinet,moisture proof,prevent dust,prevent leakage
5.Thickening the dashboard,increase the integrity of the machine and longer service life
6.Double-sided operation,so that people can operate in tow realizations conveniently and quickly
7.Rotary oil-way of work station make add oil more conveniently.
Model Type
GW42D-4 (automatic) YEJ 100L2-4 (Brake motor)
GW42D-1 (manual) Y100L2-4
• POWER: 3,0 kw-4P
• SAFETY: IP44, IP54, IP55 (dust proof)
• EFFICIENCY: 81 %
• CE Certificate of adequacy.
* Both kinds of motors automatic and manual have 1 year warranty.
* VOLTAGE OPTIONS: any voltage from 220 to 440 / 220-380 (switchable)
* FREQUENCY OPTIONS: 50Hz / 60Hz
Steel Bar Bender GW42D Automatic/Manual
Bending Capacity
6-38mm(ob ≤450N/mm2)
6-36 mm (ob ≤650N/mm2)
Operation
Automatic
Manual
Type of Motor
Y100L2-4 (Brake motor)
Y100L2-4
Motor Power
3 KW-4P
3 KW-4P
Motor Rotation Speed
1430 R/min
1430 R/min
Speed of Working Disk
8-11 R/min
8-11 R/min
Noise Value (1m away)
≤80dB(A)
≤75dB(A)
Weight
310 Kg.
305Kg.
Dimension
850×760×800mm
850×760×800mm
Certification
2006/42/EC - 2006/95/EC
From the supplier
Advantage:
1.The latest heavy-duty gear box assembly,spindle is a maintenance free
2.Column and spool adopt high quality alloy steel,high temperature quenching treatment,higher hardness,more wear-resisting
3.Increase heavy of disc and square steel,Never deformation,bend bar more accurately
4.Enclosed electric cabinet,moisture proof,prevent dust,prevent leakage
5.Thickening the dashboard,increase the integrity of the machine and longer service life
6.Double-sided operation,so that people can operate in tow realizations conveniently and quickly
7.Rotary oil-way of work station make add oil more conveniently.
Model Type
GW42D-4 (automatic) YEJ 100L2-4 (Brake motor)
GW42D-1 (manual) Y100L2-4
• POWER: 3,0 kw-4P
• SAFETY: IP44, IP54, IP55 (dust proof)
• EFFICIENCY: 81 %
• CE Certificate of adequacy.
* Both kinds of motors automatic and manual have 1 year warranty.
* VOLTAGE OPTIONS: any voltage from 220 to 440 / 220-380 (switchable)
* FREQUENCY OPTIONS: 50Hz / 60Hz
Steel Bar Bender GW42D Automatic/Manual
Bending Capacity
6-38mm(ob ≤450N/mm2)
6-36 mm (ob ≤650N/mm2)
Operation
Automatic
Manual
Type of Motor
Y100L2-4 (Brake motor)
Y100L2-4
Motor Power
3 KW-4P
3 KW-4P
Motor Rotation Speed
1430 R/min
1430 R/min
Speed of Working Disk
8-11 R/min
8-11 R/min
Noise Value (1m away)
≤80dB(A)
≤75dB(A)
Weight
310 Kg.
305Kg.
Dimension
850×760×800mm
850×760×800mm
Certification
2006/42/EC - 2006/95/EC
About the supplier
Main products: Other Small Construction Vehicles,Other Construction and Agriculture Machinery（Indoor Area）
- ✓Exhibited at 10 of the last 10 Canton Fairs
- ✓Industry and Trade Company
- ✓Founded 1994
- ✓Canton Fair Premium Supplier
- ✓National high-tech enterprise
- Exhibited at 10 of the last 10 Canton Fairs
- Industry and Trade Company
- Founded 1994
- Canton Fair Premium Supplier
