YZPP-80Liquid Blister Packaging machine
WENZHOU CHANGS INTERNATIONAL
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
YZPP-80Liquid Blister Packaging machine
WENZHOU CHANGS INTERNATIONALThe supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if unreachable
About this product
- Materials: Metal
- Size: 1840*900*1300
- Color: grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: Metal
- Size: 1840*900*1300
- Color: grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | Metal |
|---|---|
| Size | 1840*900*1300 |
| Color | grey |
Product details
| Materials | Metal |
|---|---|
| Size | 1840*900*1300 |
| Color | grey |
From the supplier
Features:
1.It adopts the newest type high-power transmission mechanism to arrange the chain and drive the main driving shaft. The errors and noises of other gear wheel transmission can be avoided.
2.Imported controlling system is adopted; also it can be equipped with detecting and rejection function device for number of medicines according to the user’s requirement.
3.It adopts photoelectrical controlling system to make PVC, PTP, Aluminum/Aluminum material to be automatically fed and waste side to be cut automatically to guarantee the Synchronous stability of over- length distance and multi stations.
4.It can be optional equipped with photocell correction device, imported stepper motor traction and image- character register to optimize packing grade.
5.The machine is suitable for industries of foodstuff, medicine, medical instruments, hardware, electronics and etc for packing.
Technical Specification：
Model
YZPP-80
Punch frequency
10-20times/min
Production capacity
2400plates/hour
Max. Forming area & Depth
105x70(standard depth ≦15mm), Max. Depth 25mm( As adjusted
Standard Stroke range
30-80mm(can be designed as per user’s required)
Standard plate size
80x70mm (can be designed as per user’s required)
Air pressure
0.4-0.6Mpa
Compressed air required
Air compressor≥0.3m3/min
Total power supply
220V 50Hz 2.8Kw
Main motor
0.75Kw
PVC hard Film
0.15-0.5*110 (mm)
PTP Aluminum film
0.02-0.035*110 (mm)
Dialysis Paper
50-100g*110（mm）
Mould cooling
Tap water or Recycling water
Overall Dimension
1840x900x1300 (mm)(LxWxH)
Weight
Net 480kg Gross weight: 550kg
Noise index
Work process：
1.Forming ( up and down heating)
2. Heating Sealing ( up heating)
3.Embossing
4.Impression
5. Cutter
6. Finished product output
From the supplier
Features:
1.It adopts the newest type high-power transmission mechanism to arrange the chain and drive the main driving shaft. The errors and noises of other gear wheel transmission can be avoided.
2.Imported controlling system is adopted; also it can be equipped with detecting and rejection function device for number of medicines according to the user’s requirement.
3.It adopts photoelectrical controlling system to make PVC, PTP, Aluminum/Aluminum material to be automatically fed and waste side to be cut automatically to guarantee the Synchronous stability of over- length distance and multi stations.
4.It can be optional equipped with photocell correction device, imported stepper motor traction and image- character register to optimize packing grade.
5.The machine is suitable for industries of foodstuff, medicine, medical instruments, hardware, electronics and etc for packing.
Technical Specification：
Model
YZPP-80
Punch frequency
10-20times/min
Production capacity
2400plates/hour
Max. Forming area & Depth
105x70(standard depth ≦15mm), Max. Depth 25mm( As adjusted
Standard Stroke range
30-80mm(can be designed as per user’s required)
Standard plate size
80x70mm (can be designed as per user’s required)
Air pressure
0.4-0.6Mpa
Compressed air required
Air compressor≥0.3m3/min
Total power supply
220V 50Hz 2.8Kw
Main motor
0.75Kw
PVC hard Film
0.15-0.5*110 (mm)
PTP Aluminum film
0.02-0.035*110 (mm)
Dialysis Paper
50-100g*110（mm）
Mould cooling
Tap water or Recycling water
Overall Dimension
1840x900x1300 (mm)(LxWxH)
Weight
Net 480kg Gross weight: 550kg
Noise index
Work process：
1.Forming ( up and down heating)
2. Heating Sealing ( up heating)
3.Embossing
4.Impression
5. Cutter
6. Finished product output
About the supplier
Main products: Screen Printing Machine ,Non-woven Fabric Machinery
- ✓Exhibited at 10 of the last 10 Canton Fairs
- ✓Foreign Trade Company
- ✓Founded 2004
- Exhibited at 10 of the last 10 Canton Fairs
- Foreign Trade Company
- Founded 2004
