150lb ansi Electric actuator for butterfy valve ball valve 50NM-2000NM

Pov Fluid Control Technology (Wuhu) Co., Ltd
10/10 fairsManufacturerModel POE-05
150lb ansi Electric actuator for butterfy valve ball valve 50NM-2000NM
Price on request

The supplier hasn’t listed a price. We can get their current prices and MOQ.

Verify from $29 · written report in 3 business days · 100% refund if not satisfied

About this product

  • Materials: Aluminum alloy
  • Size: 50NM
  • Color: any color
  • Exports to: Africa, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Others
  • Made in: Anhui, China
Product details
MaterialsAluminum alloy
Size50NM
Colorany color
From the supplier
ModelPOE-05Power supplyDC12VDC24VDC220VAC24VAC110VAC380VAC220VPower20W10WRated current3.8A2A0.21A2.2A0.48A0.15A0.24ATorque30Nm/50Nm15Nm/30Nm/50NmRunning time6S/10S10s/20S/30SControl loopType A,B,C,D,E,F,G,HRotation angle0°~360° adjustableWeight2.4KGInsulation resistance100MΩ/300VDC100MΩ/500VDVoltage endurance level500AC/1min500VAC/1minProtection levelIP67Ambient temperature-25℃~+60℃Installation angle360° any angleShell materialAluminum alloy precision press-forged pieceOptional featuresdehumidifierModelPOE-10Power supplyDC12VDC24VDC220VAC24VAC110VAC380VAC220VPower40W23WRated current4.8A2.4A0.32A3A0.64A0.19A0.32ATorque100Nm50Nm/60Nm/100NmRunning time10S13s/20S/30SControl loopType A,B,C,D,E,F,G,HRotation angle0°~90° adjustableWeight4.2KGInsulation resistance100MΩ/300VDC100MΩ/500VDVoltage endurance level500AC/1min1500VAC/1minProtection levelIP67Ambient temperature-25℃~+60℃Installation angle360° any angleShell materialAluminum alloy precision press-forged pieceOptional featuresdehumidifierModelPOE-20/40Power supplyDC24VDC220VAC24VAC110VAC380VAC220VPower40W60WRated current8A0.35A5A0.9A0.25A0.48ATorque200Nm200Nm/400NmRunning time10S15S/20SControl loopType A,B,C,D,E,F,G,HRotation angle0°~90° adjustableWeight7.2KGInsulation resistance100MΩ/300VDC100MΩ/500VDVoltage endurance level500AC/1min1500VAC/1minProtection levelIP67Ambient temperature-25℃~+60℃Installation angle360° any angleShell materialAluminum alloy precision press-forged pieceOptional featuresdehumidifierModelPOE-50/60Power supplyDC24VDC220VAC24VAC110VAC380VAC220VPower90WRated current7A0.9A8A2A0.45A0.92ATorque500Nm/600NmRunning time15S/30S/60SControl loopType A,B,C,D,E,F,G,HRotation angle0°~90° adjustableWeight8KGInsulation resistance100MΩ/300VDC100MΩ/500VDVoltage endurance level500AC/1min1500VAC/1minProtection levelIP67Ambient temperature-25℃~+60℃Installation angle360° any angleShell materialAluminum alloy precision press-forged pieceOptional featuresdehumidifierModelPOE-100POE-200Power supplyAC24VAC110VAC380VAC220VAC24VAC110VAC380VAC220VPower100W100WRated current9A2.2A0.48A1.2A9A2.2A0.48A1.2ATorque300Nm/800Nm/1000Nm2000NmRunning time15S/30S/50S100SControl loopType A,B,C,D,E,F,G,HRotation angle0°~90° adjustableWeight11.5KG12.1KGInsulation resistance100MΩ/500VDVoltage endurance level1500VAC/1minProtection levelIP67Ambient temperature-25℃~+60℃Installation angle360° any angleShell materialAluminum alloy precision press-forged pieceOptional featuresdehumidifier


Butterfly valves



Factory manufacturer



ISO CE certificate



Packaging


FAQS


1. How soon can I get a price quote?

Once we know the Size, material, drive method we can provide you with one competitive price quote within 24 hours.


2. Can I get a sample?

Yes, the samples are free for you. But you need to offer one courier account NO. to afford the fee for samples shipping. The samples’ sending usually takes 3-5days.


3. How can my order produced by my brand?

Yes, you can. Pls offer your brand or LOGO design to us, then we could produce all goods with your brand or LOGO.


4. Will you match competitors' prices?

If you find a lower price elsewhere for the exact same specification, we will meet or beat that price as long as it is a little higher than our cost price.


5. Is there a minimum order requirement?

Our minimum order quantity is 1pcs


6. How can I be your sole agent in our country?

Welcome you to become our sole agent firstly. According to different countries’ demand, if your yearly purchase quantity from us can reach 10000 to 30000 pcs you could be our sole agent in your country. If you wanna know exact quantity requirement for each country, pls feel free to contact us at any time.
