AUTOMOTIVE HVAC MOULD /HVAC MOULD/mould maker
SUZHOU HENGXIANG IMPORT & EXPORT CO., LTD.
See what’s includedHide breakdown
- FOB goods (100)
- $25,050,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $876,750
- Section 301 tariff (25.0%)
- $6,262,500
- Customs fees (MPF/HMF)
- $31,947
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $25,050,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $876,750
- Section 301 tariff (25.0%)
- $6,262,500
- Customs fees (MPF/HMF)
- $31,947
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
AUTOMOTIVE HVAC MOULD /HVAC MOULD/mould maker
SUZHOU HENGXIANG IMPORT & EXPORT CO., LTD.See what’s includedHide breakdown
- FOB goods (100)
- $25,050,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $876,750
- Section 301 tariff (25.0%)
- $6,262,500
- Customs fees (MPF/HMF)
- $31,947
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $25,050,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $876,750
- Section 301 tariff (25.0%)
- $6,262,500
- Customs fees (MPF/HMF)
- $31,947
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: steel
- Size: Customizable
- Color: customizable
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: steel
- Size: Customizable
- Color: customizable
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | steel |
|---|---|
| Size | Customizable |
| Color | customizable |
Product details
| Materials | steel |
|---|---|
| Size | Customizable |
| Color | customizable |
From the supplier
Without the heating and air conditioning systems in today’s modern vehicles, we would all be miserable driving to our destinations. We take for granted the heat that keeps us warm in the winter months, and the cool air that refreshes in the summer time. Let’s take a look at how both systems work to keep us comfortable all year round.
Is pretty experienced in HVAC mould field, who had processed over 100 HVAC mould jobs for both oversea and domestic OEM customers.
Each vehicle HVAC module has six primary components, Evaporator, Heater Core, Blower Assembly, Actuators, Sensors and Filters. Car air conditioner molds are needed for HVAC housings/covers and doors.
The HVAC systems basally includes defogger, defroster, vent central/side, feet front and feet rear modes. These modes are mainly areas for HVAC molds. The mold in HVAC fields typically needs several circles DFMA for OEM’s R&D engineers. HVAC designer and mold designers for mold in HVAC fields will have full communication at the later R&D stage.
HVAC is the short name for Heating, ventilation and air conditioning.
BASIC INFOMATION
Name
HVAC mould
Plastic resin
>PP+TD20
Mould dimension(mm)
870*620*450
Mould weight (T)
1.5T
Mould cavity steel
China 718H
Mould Core steel
China 718H
Gate system
4 YUDO drops with pin-valve gate hot runner system, switching into cold runner by edge injection gate
Manufacture time (day)
50~60 DAYS
Mould life (ten thousand)
≥50
Cycle time
70~75 S
Cooling line connector type
DME NS350 SERIES quick coupling, connected to main water manifold by FST100 MS joint connector, excellent cooling system design
From the supplier
Without the heating and air conditioning systems in today’s modern vehicles, we would all be miserable driving to our destinations. We take for granted the heat that keeps us warm in the winter months, and the cool air that refreshes in the summer time. Let’s take a look at how both systems work to keep us comfortable all year round.
Is pretty experienced in HVAC mould field, who had processed over 100 HVAC mould jobs for both oversea and domestic OEM customers.
Each vehicle HVAC module has six primary components, Evaporator, Heater Core, Blower Assembly, Actuators, Sensors and Filters. Car air conditioner molds are needed for HVAC housings/covers and doors.
The HVAC systems basally includes defogger, defroster, vent central/side, feet front and feet rear modes. These modes are mainly areas for HVAC molds. The mold in HVAC fields typically needs several circles DFMA for OEM’s R&D engineers. HVAC designer and mold designers for mold in HVAC fields will have full communication at the later R&D stage.
HVAC is the short name for Heating, ventilation and air conditioning.
BASIC INFOMATION
Name
HVAC mould
Plastic resin
>PP+TD20
Mould dimension(mm)
870*620*450
Mould weight (T)
1.5T
Mould cavity steel
China 718H
Mould Core steel
China 718H
Gate system
4 YUDO drops with pin-valve gate hot runner system, switching into cold runner by edge injection gate
Manufacture time (day)
50~60 DAYS
Mould life (ten thousand)
≥50
Cycle time
70~75 S
Cooling line connector type
DME NS350 SERIES quick coupling, connected to main water manifold by FST100 MS joint connector, excellent cooling system design
