1. Scope of Application

It is suitable for automatic quantitative packaging of materials with good fluidity (such as: rice, white sugar, feed, plastic granules, etc.).

2. Features

(1) Weighing instrument + PLC dual-core control technology, the number of A/D conversions reaches 480 times per second. It ensures the strict requirements of the weighing speed and weighing accuracy of the machine.

(2) We adopt the three-sensor structure, the layout of the weighing hoppers is balanced, and the force is reasonable, which improves the service life of the machine, and is not disturbed by the vibration of the workshop machine, and has high stability and anti-interference ability.

(3) Friendly man-machine interface, simple and convenient equipment operation, reduce labor intensity, improve the intelligent level of workshop operation, intelligent storage of production reports, and data communication functions.

(4) In order to ensure food safety, we use stainless steel for feeding, weighing hoppers and parts which touch the grains, it is safe and hygienic. The interior is polished smooth to eliminate dead ends and no residual materials, preventing the remaining rice from mildew and rancidity affecting the quality of rice.

(5) To eliminate rodent infestation and acidification corrosion, we have adopted a closed studio, and all lines, sensors, and solenoid valves have used steel wire grooves or protective iron boxes, which have also completely isolated the corrosion and wear of rice flour and water vapor on the cylinder and sensors, prolonging the working life. equipment trouble-free operating time.

(6) External adjustment mechanism handle mechanism. The scaled handle adjustment device is used to adjust the size of the "feeding port" to the best working mode for rice with different water content and different grain shapes to ensure the weighing effect.

(7) The cylinder works frequently and has high strength. The double-cylinder discharge mechanism developed by us solves many problems such as the high frequency of use of the cylinder, the short life of the cylinder, the solenoid valve and other components, many failures, and unstable performance.

(8) Digital intelligent automatic lifting conveyor, the conveyor can quickly switch to the appropriate position according to different packages, and the lifting height of different varieties can be memorized.

(9) It’s easy to turn, rotating column, multi-functional sealing method, according to different packaging and different sealing forms, our standard with a sewing machine, but also be available with a heat sealing machine that can be switched by rotating, so that users can feel the convenient and easy-to-use experience.

(10) The sliding column can be adjusted, which is suitable for a variety of operation modes, allowing you to make ordinary bag sewing, hemming bag sewing, heat-sealing bag sewing, and the operating distance as you like, presenting an indescribable joy. (Optional folding and heat sealing machine)

3. Technical parameters (applicable to rice)

Model

DCS-50FB3+

Display Mode

Color screen display and control

Weighing range

5-25Kg

Weighing speed

700～1080 Bags/Hours

Number of buckets（Hopper）

2

Maximum weight of a single buckets

25kg

Number of load cells

3

Graduation value

2g

Accuracy level

X（0.2）

Gas consumption

（0.4～0.5）MPa 16.7L/min

Power

1.1kW

Working environment

Relative humidity≤90%, temperature (0～40)℃

Power requirements

AC220V±5% 50Hz；AC380V±5% 50Hz

Dimension（mm）

3167×1044.5×2692.5mm

4. Main configuration

Component Name

Brand

Weighing control instrument

GM or AMP

PLC

Omron or Delta

Color touch screen

Kunlun Tongtai

Weighing sensor

Mettler Toledo (USA)/ HBM (Germany)

Electromagnetic valve

Taiwan mindman

Photoelectric Sensors

Omron or SICK

Proximity switch

Omron

Cylinder

AirTAC

Sewing machine

Qinggong or Dechao
