About this product
- Materials: 100% coppoer
- Size: 2700X1050X1400
- Color: Yellow
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Others
- Made in: Fujian, China
About this product
- Materials: 100% coppoer
- Size: 2700X1050X1400
- Color: Yellow
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Others
- Made in: Fujian, China
Product details
| Materials | 100% coppoer |
|---|---|
| Size | 2700X1050X1400 |
| Color | Yellow |
From the supplier
Genset Model
APC-80
Prime Power (kw/kva)
80 / 100
Standby Power(kw/kva)
88 / 110
Voltage (v)
440/254
Rated Speed (rpm)
1500
Frequency (Hz)
50
Rated Current (A)
131.2
Connection:
3 phase 4 wire
Power Factor:
0.8
Engine Model:
6BT5.9-G2
Alternator Model:
UCI274C
Net Weight (kgs)-Open
1450
Net Weight (kgs)-Silent
1900
Dimensions (mm)-Open
2150×830×1450
Dimensions (mm)-Silent
2700X1050X1400
Voltage Available: 50Hz: 380-400-415V/220-230-240V; 60Hz: 220-380-416-440-480V/110-208-220-240V
Any special voltage is also available as client’s request
Prime Power: comply with GB/T2820-97(eqv.ISO8528). Genset can run unlimitedly under certain power range. One hour 10% over load in every 12 running hours is allowed;
Standby Power: standby power is the limit value of maximum output for emergency use. It is off-oil power, overloading is prohibited
Standard Configuration:
- u Engine: DCEC Cummins 6BT5.9-G2
- u Cooling Fan with fan guard and front guard
- u Alternator: Single bearing, IP23, H class
- u 24V Charger
- u Shock Absorber
- u Dry Air Filter. Dual Fuel Filter. Engine Oil Filter.
Coolant Filter.
- u MCCB Circuit Breaker
- u Standard Control Panel; ATS for optional
- u 2x12V Start Battery with connecting cable
- u Storage Battery and battery line, Exhaust pipe,
Corrugated pipe for anti-vibration, Cone Tube,
Flange, Muffler
- u Soundproof Enclosure/Canopy for optional
- u Documents
Quality Assurance:
- l Factory Inspection, the test items before delivery are mainly as follows:
- ü Each genset shall be put into commission more than 4 hours totally. They are tested on idle load, fully load and 10% overload;
- ü The noise level is tested
- ü All of the meters on the control panel shall be tested
- ü The appearance of the genset and all of the label and nameplate shall be checked
- l Warranty
12 months or 1000 running hours from shipment date. If the quality problem arise during the warranty period, and verified the problem is caused by our genset-body instead of external or natural reasons. (Refer to all kinds of natural disaster, shipping, loading, unloading, wrong-operation, etc), we will supply the relevant spare parts free of charge for maintenance; after the warranty period, we can supply the required spare parts for you under cost prices.
Engine Parameter:
Manufacturer/Model: Aspiration: Fuel System:
Cylinder numbers
Displacement:
Bore x Stroke
Compression Ratio:
Max. Power:
Governing System:
DCEC, Cummins, 6BT5.9-G2, 4 stroke
Turbocharged, Inercooled
A/AD Fuel Pump,
6 cylinders in line
5.9 L
102 x 120 mm
17.5 : 1
101KW / 136HP
Electrical
Exhaust System
Exhaust Volume:
Exhaust temperature:
Max. Allowed Back Pressure:
16.8 m³/min
565 ℃
10 KPa
Intake System
Max. Allowed Pressure:
Gas Volume:
Air Flow:
6.35 kPa
6.48 m³/min
158 m³/min
Fuel System
100% Load (Prime):
75% Load(Prime):
50% Load (Prime):
214 g/kw.h
216 g/kw.h
217 g/kw.h
Lube System
Oil Capacity:
Oil Consumption:
Bottom shell oil capacity:
Oil Pressure at rated speed:
16.4 L
≦4g/kw.h
14.2 L
345 kPa
Cooling system
Coolant Capacity:
Thermostat:
Max. Water Temperature:
27 L
82-95℃
104℃
