About this product
- Materials: die-cast aluminum alloy(frame size:025 to 090);cast iron;20CrMnTi;wearable stammum bronze alloy
- Color: blue;black
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: die-cast aluminum alloy(frame size:025 to 090);cast iron;20CrMnTi;wearable stammum bronze alloy
- Color: blue;black
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | die-cast aluminum alloy(frame size:025 to 090);cast iron;20CrMnTi;wearable stammum bronze alloy |
|---|---|
| Color | blue;black |
Product details
| Materials | die-cast aluminum alloy(frame size:025 to 090);cast iron;20CrMnTi;wearable stammum bronze alloy |
|---|---|
| Color | blue;black |
From the supplier
STRUCTURE FEATURES
1、 Large in output torque.
2、 Smooth in running and low in noise, can work long time in dreadful conditions.
3、 High in radiating efficiency.
4、 Good-looking in appearance, durable in service life and small in volume.
5、 Suitable for omnibearing installation.
APPLICATION FIELD
Packing machinery、chemical machinery、environmental protection industries、 food machinery、auto assembling line machinery etc.
SURFACE PAINTING
Aluminum alloy housing:
1. Shot blasting and special antiseptic treatment on the aluminum alloy surface.
2. After phosphating,paint with RAL5010 blue or silvery white paint.
Cast iron housing:
First paint with red antirustpaint,then paint with RAL5010 blue or silvery white paint.
Housing: Alu dia casting from size 25-90
Iron Casting from size 110-150
Worm: 20CrMnTi with carburization to 58-62HRC
Worm wheel: Bronze CuSn 12-2
Ratio from 5-100 (Single kit), 300-5000(Double kits)
Max Output Turque : 9650 Nm (Single kits)
13500 Nm (Double kits)
Reverse self-locking function
Suitable for omnibearing installation
Small size, light in weight and non-rusting
Oil: Sythetice oil from Size 25-90, Mineral oil from Size 110-150
Optional Accessories: Single output shaft/Double output shaft/Torque Arm/Dust Cover/Bush/Conversion shaft
From the supplier
STRUCTURE FEATURES
1、 Large in output torque.
2、 Smooth in running and low in noise, can work long time in dreadful conditions.
3、 High in radiating efficiency.
4、 Good-looking in appearance, durable in service life and small in volume.
5、 Suitable for omnibearing installation.
APPLICATION FIELD
Packing machinery、chemical machinery、environmental protection industries、 food machinery、auto assembling line machinery etc.
SURFACE PAINTING
Aluminum alloy housing:
1. Shot blasting and special antiseptic treatment on the aluminum alloy surface.
2. After phosphating,paint with RAL5010 blue or silvery white paint.
Cast iron housing:
First paint with red antirustpaint,then paint with RAL5010 blue or silvery white paint.
Housing: Alu dia casting from size 25-90
Iron Casting from size 110-150
Worm: 20CrMnTi with carburization to 58-62HRC
Worm wheel: Bronze CuSn 12-2
Ratio from 5-100 (Single kit), 300-5000(Double kits)
Max Output Turque : 9650 Nm (Single kits)
13500 Nm (Double kits)
Reverse self-locking function
Suitable for omnibearing installation
Small size, light in weight and non-rusting
Oil: Sythetice oil from Size 25-90, Mineral oil from Size 110-150
Optional Accessories: Single output shaft/Double output shaft/Torque Arm/Dust Cover/Bush/Conversion shaft
