About this product
- Materials: Stainless steel
- Size: 2.0mm ,2.5mm, 3.2mm, 4.0mm, 5.0mm
- Color: grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America
- Made in: Hebei, China
About this product
- Materials: Stainless steel
- Size: 2.0mm ,2.5mm, 3.2mm, 4.0mm, 5.0mm
- Color: grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America
- Made in: Hebei, China
Product details
| Materials | Stainless steel |
|---|---|
| Size | 2.0mm ,2.5mm, 3.2mm, 4.0mm, 5.0mm |
| Color | grey |
Product details
| Materials | Stainless steel |
|---|---|
| Size | 2.0mm ,2.5mm, 3.2mm, 4.0mm, 5.0mm |
| Color | grey |
From the supplier
A062
GB：E309L-16
AWS：E309L-16
Applications：Choice for same type of stainless steel like equipments from synthetic fiber or petrochemical industry, composite steel, dissimilar steel, etc., also applicable for surfacing welding on lining of nuclear reactor’s pressure vessel and inner component welding.
According with GB E309L-16
Corresponding with AWS E309L-16
Introduction: A062 is a kind of ultra-low-carbon Cr23Ni13 stainless steel electrode with lime-titania type coating. AC/DC. Due to the low carbon content, it can resist intercrystalline corrosion.
Applications: Choice for same type of stainless steel like equipments from synthetic fiber or petrochemical industry, composite steel, dissimilar steel, etc., also applicable for surfacing welding on lining of nuclear reactor’s pressure vessel and inner component welding.
Chemical Composition of Deposited Metal (%)
Chemical Composition
C
Mn
Si
S
P
Ni
Mo
Cr
Guarantee Value
≤0.04
0.5~2.5
≤0.90
≤0.030
≤0.040
12.0~14.0
≤0.75
22.0~25.0
Mechanical Properties of Deposited Metal
Test Item
Rm(MPa)
A(%)
Guarantee Value
≥520
≥25
Reference Current (AC, DC+)
Electrode Diameter(mm)
φ2.0
φ2.5
φ3.2
φ4.0
φ5.0
Welding Current (A)
40~80
50~100
70~130
100~160
140~200
Instructions:
1.The electrodes should be baked under 200-250℃ for an hour before welding.
2.D/C is preferred for better welding and the current should not be too strong.
Packing details: In carton of 20kgs/net, consisting of 8 boxes x 2.5kgs for 2.5mm, & 4 boxes x 5kgs for other sizes.
With/ without pallets (Fumigation-free pallets) upon customer’s request.
From the supplier
A062
GB：E309L-16
AWS：E309L-16
Applications：Choice for same type of stainless steel like equipments from synthetic fiber or petrochemical industry, composite steel, dissimilar steel, etc., also applicable for surfacing welding on lining of nuclear reactor’s pressure vessel and inner component welding.
According with GB E309L-16
Corresponding with AWS E309L-16
Introduction: A062 is a kind of ultra-low-carbon Cr23Ni13 stainless steel electrode with lime-titania type coating. AC/DC. Due to the low carbon content, it can resist intercrystalline corrosion.
Applications: Choice for same type of stainless steel like equipments from synthetic fiber or petrochemical industry, composite steel, dissimilar steel, etc., also applicable for surfacing welding on lining of nuclear reactor’s pressure vessel and inner component welding.
Chemical Composition of Deposited Metal (%)
Chemical Composition
C
Mn
Si
S
P
Ni
Mo
Cr
Guarantee Value
≤0.04
0.5~2.5
≤0.90
≤0.030
≤0.040
12.0~14.0
≤0.75
22.0~25.0
Mechanical Properties of Deposited Metal
Test Item
Rm(MPa)
A(%)
Guarantee Value
≥520
≥25
Reference Current (AC, DC+)
Electrode Diameter(mm)
φ2.0
φ2.5
φ3.2
φ4.0
φ5.0
Welding Current (A)
40~80
50~100
70~130
100~160
140~200
Instructions:
1.The electrodes should be baked under 200-250℃ for an hour before welding.
2.D/C is preferred for better welding and the current should not be too strong.
Packing details: In carton of 20kgs/net, consisting of 8 boxes x 2.5kgs for 2.5mm, & 4 boxes x 5kgs for other sizes.
With/ without pallets (Fumigation-free pallets) upon customer’s request.
