Multi payment functions are available on Eaglestar fuel dispensers. Bank POS, Priority member card, oil company petrol card, RFID system, through all these different payment ways, the stations can attract more customers for fuel and non fuel goods sales.

Following model support 6 nozzles: EG5 EG6 EG7

Model Nozzle Product Meter Displays (both sides) EG5-636(G) or (S) 6 3 6 6 EG5-634(G) or (S) 6 3 6 4 EG5-632(G) or (S) 6 3 6 2

Model Nozzle Product Flow Meter

Display

(both sides)

EG6-632(G or S) 6 3 6 2

Basic models Optional features

Standard duty 50 l/min.

Heavy duty 80 l/min

Combined standard duty and heavy duty

• 7-7-5 LCD display

• Single phase motor (standard 3 phase)

• Non resettable mechanical totaliser

• Steel keypad for comfortable operation experience

• Emergency button

• Breakaway coupling

• Card reader for oil company petrol card

• Priority member card

• Printer

• External reusable filter

• Submersible type

• Customized logo painting on front panel

Detailed description

Flow Meter

Flow meter is paramount on fuel dispenser unit. Eaglestar flow meter is engineered to retain its precision over complete lifetime. The unique internal structure and high quality components keep very less drift in the lifetime of the meter.

Gear pump

There are two types of pumping unit, vane and gear, which can be chosen on EG3 series. Comparison with vane pump, Gear type pumping unit has more virtual features. Strong suction power, high flow duty 50/90 liter per minute, two filters, all these can bring it a better performance in the harshest conditions with a variety of fuel types.

Latest ARM Mainboard

Eaglestar's new generation STAR main board uses the latest ARM CPU processor to achieve more command feature, Easy configuration and high safety control.

More functions can be expanded on STAR main board such as printing, POS, Smart Card, Priority Card etc.

The high quality industrial electronic components ensure the excellent performance on power surge, electrostatic shock And electromagnetic interference

LED Display

The high quality LED display brings very bright light for night fueling.The low electrical power consumption makes the units cost effective.

Anti Power Fluctuation

UL listed motor offer the best performance. Overload protection is robust in various conditions. High quality capacitors allow the motor to start in lower voltage power supply. The stations have less maintenance for the motor.

Power board cope with wide range power fluctuation.

The enhanced electrical system protect the PCB boards from lighting.

Petro card solution

Petrol card solution offer customers one flexible payment method.Through card,fueling station can get prepayment and make more promotions to attract more customers.

Other Accessories keypad emergency stop button electromagnet totalizer explosion proof solenoid valve junction box vane pump nozzle and hose nozzle hanger Technical parameter Environmental conditions Technical specification

• Temperature : -25°C to +55°C
• Humidity : 5% to 95%

• Accuracy : ±0.25%
• Flow rate : 50l/min. 80liter/min for heavy duty
• Digits for sales : 7 digits
• Digits of volume : 7 digits
• Digits of unit price : 5 digits
• Power Supply : AC220V (-15% ~ +10%) 50/60Hz
• AC380V (-15% ~ +10%) 50/60Hz
• Mechanical totaliser : 7 digits
• Electronic totaliser : 10 digits

Company Information

FAQ

1. Q1: What are the advantages of your company?
   A1: We are the manufacturer. We have more than 20,000m3 factory in Zhengzhou city and Puyang city, Henan province. This is different from trading company.

   A2: With 15 years’ experience, Eaglestar is one professional manufacturer for fuel gas station equipment including fuel dispenser, auto tank gauge, fuel management system, fleet RFID POS system and other equipment.

   A3: With 20 years’ experience, Eaglestar provide high quality total solution for LPG, LNG, LCNG, CNG area. This is most different to other new comer supplier with low quality, low price.


   Q2:What certificates do you have?

   A: OIML, CE, CNEX, MC, ISO9001, ISO14000. ATEX in process now. Interface to ITL, Technotrade and other Russian POS companies


   Q3: What is terms of payment?MOQ?
   A: We accept T/T,LC. MOQ is 1 set.


   Q4:How long is your warranty?

   A1:12 months from the installation or 16 months from the date of bill of lading which comes earlier occurs.

   A2: We offer technical support online free of charge for whole life time of equipment.


   Q5: How can i get your quick feedback?
   A: IF we are offline, Send inquiry or leave us a message with your spec, detailed requirement and your whatsApp number. More specification, quicker feedback.
