Engine :

Engine brand : Chinese YTO engine

Cooling method : closed water cooling or air force cooled

Starting method : electric start

Alternator :

Brand: Stamford or Leroysomer or our BOSS series brushless

Rated voltage : 400 / 230V, 380 / 220, 220 / 110, etc

Rated Frequency : 50 / 60Hz

Power factor : 0.8

Phase : 3-phase, 4-wire

Connection : Y or other type connection

Applications :

1 . Industrial area : real estate , hospital , hotel , bank , construction , factory , oil field , airport , mining , railway

2 . Home use : personal use for house , camping , party , etc

3 . Telecom , Mobile tower , etc

4 . Island , Desert or any place without electricity

5 . As for emergency equipment special for natural disasters , such as typhoon , earthquake , heavy snow

6 . Standby power or main power , indoor or outdoor using .

About YTO Engine:

1.Yto is a reliable international famous brand, and is the preferred power of the generator set industry at home and abroad

2.Yto has the obvious advantages of strong power, large torque reserve, reliable durability and low consumption economy.

3.What's more, it have one-year warranty, if you have any other problems of quality, we are willing to provide

the accessories or technical supports for you.

PRODUCT DESCRIPTION

Frequency: 50HZ;Rotating speed: 1500Rpm

Model

Power(KW)

Capacity(KVA)

Rated current(A)

Engine Model

Stamford Type

BS-YT31

25

31

45.1

YT3B2-D

BS184G

BS-YT38

30

37.5

54.1

YT3A2Z-D

BS184H

BS-YT50

40

50

72.2

LR4B5-D

BS224D

BS-YT63

50

62.5

90.2

YT4B2Z-D

BS224E

BS-YT65

52

65

93.8

LR4B3Z-D

BS224F

BS-YT94

75

94

135.3

LR4M3L-D

BS274C

BS-YT100

80

100

144.3

LR4N5LP-D

BS274C

BS-YT125

100

125

180.4

LR6A3L-D

BS274D

BS-YT150

120

150

216.5

LR6B3L-D

BS274F

BS-YT163

130

163

234.6

LR6M3L-D

BS274F

BS-YT200

160

200

288.7

YM6H4L-D

BS274H

BS-YT225

180

225

324.8

YM6H4LF-D

BS274J

BS-YT250

200

250

360.9

YM6S4L-D

BS274K

BS-YT275

220

275

396.9

YM6S4LF-D

BS314D

BS-YT313

250

313

451

YM6S9L-D

BS314ES

BS-YT350

280

350

505

YM6S9L-DB

BS314FS

BS-YT375

300

375

541.3

YM6S9LF-D

BS314F

BS-YT400

320

400

577.4

YM6S9LF-DA

BS354C

Frequency: 60HZ;Rotating speed: 1800Rpm

Model

Power(KW)

Capacity(KVA)

Rated current(A)

Engine Model

Stamford Type

BS-YT38

30

38

54

YT3B2-D

BS184G

BS-YT40

32

40

57.6

YT3A2Z-D

BS184H

BS-YT55

44

55

79.2

LR4B5-D

BS224C

BS-YT68

54

68

97.2

YT4B2Z-D

BS224E

BS-YT70

56

70

100.8

LR4B3Z-D

BS224E

BS-YT94

78

94

140.4

LR4M3L-D

BS224G

BS-YT110

88

110

158.4

LR4N5LP-D

BS274C

BS-YT130

105

130

189

LR6A3L-D

BS274D

BS-YT165

125

165

225

LR6B3L-D

BS274E

BS-YT170

135

170

243

LR6M3L-D

BS274F

BS-YT220

180

220

324

YM6H4L-D

BS274H

BS-YT240

190

240

342

YM6H4LF-D

BS274H

BS-YT270

220

270

396

YM6S4L-D

BS274K

BS-YT315

250

315

450

YM6S4LF-D

BS314D

BS-YT350

280

350

504

YM6S9L-D

BS314E

BS-YT370

300

370

540

YM6S9L-DB

BS314F

BS-YT400

320

400

576

YM6S9LF-D

BS314G

BS-YT430

350

430

630

YM6S9LF-DA

BS314H

(1)The silent canopy we use cold-rolled sheet, all positions are stronger.

(2)Our spraying plastics all go through pre-treatment of pickling and phosphating, so that the surface of the

    painting will not change color even if placed outside for five years.

(3)Canopy color painted by customer's requirement.

(4)Strict test including 50% load,75% load,100% load and 110% Load .

(5)Forklift mouth in base frame for easy loading and discharging.

(6)Logo made by customer's requirement if order quantity ≥10units or a full container.

Q: Do you offer OEM service?

A: Yes

Q: What is your payment term?

A: 30% T/T in advance, the rest payment before shipment.  Or irrevocable L/C.

Q: What is your lead time?

A: About 30 days after receiving deposit or original L/C.But if your order with some special design, then the
    delivery time is longer.

Q: What certificates do you have?

A: We have CE, ISO. And we can apply for specific certificate for different country such as SONCAP for Nigeria,
     CIQ for Egypt, SASO for Saudi Arabia, etc

Q:What is your MOQ?

A: Above 1pc

Q. Which port do you often use when export?

A: Fuzhou Port, or as customer request.

Q.How to choose the power?

A.:Collect all power of your equipments,take the current into your consideration.

Q.What is the difference between Prime power and Standby power?

A.:Prime power is 12hours continous power,one hour 10% over load in every 12 running hours is allowed.

Standby power is the limit value of maximum output for emergency use. Overloading is prohibited

Q.What about the warranty

Guarantee for one year or 1000 hours (accord to whichever reach first) from ex-factory date.During the guarantee period,
our company will provide the free easy damaged spare part for problems caused by our quality of production or raw material
except the damageable spare parts of diesel engine caused by customer's incorrect man made operation.After expiration,

our company provides cost parts maintenance for gen-set.
